COGIS

Facility Detail

COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-045-06529		Well Classification: GW Status: PR - 8/28/1987
Well Name/No:W-34-2 FEDERAL #W-34-2
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:TEP ROCKY MOUNTAIN LLC - 96850
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:12709
Facility Status:PRStatus Date8/28/1987
FacilityID:210771LocationID:428673
County:GARFIELD #045Location:NWSE 2 7S95W 6
Field:PARACHUTE - #67350Elevation:5579 ft.
Basin:PICEANCE BASIN
Planned Location:1670FSL  1438 FELLat/Long: 39.464089 / -107.961192Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 39.464238 / -107.961501Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 8/28/1987             Measured TD: 3063 ft.    Vertical TD: 3063 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 8/28/1987
Wellbore Permit
Permit #:870108 Expiration Date:6/26/1987
Proposed Depth/Form:
Surface Mineral Owner Same:Not available
Mineral Owner:FEDERALSurface Owner:Not available
Unit: Unit Number:C-05173
Formation And Spacing:Code: WSTC , Formation: WASATCH , Order: 0 , Unit Acreage: 160, Drill Unit: SE4
Wellbore Completed
Completion Date:8/28/1987
Measured TD:3063 ft.Measured PB depth:2909 ft.
True Vertical TD:3063 ft.True Vertical PB depth:
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 287 ft., Weight: 32 , Citings Type: ACTUAL
Cement:Sacks: 200, Top: 0 ft., Bottom: 287 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 6.5 in., Size: 4.5 in., Top: 0 ft., Depth: 3058 ft., Weight: 10.5 , Citings Type: ACTUAL
Cement:Sacks: 400, Top: 500 ft., Bottom: 3058 ft., Determination Method: CALC
FormationInterval TopLog BottomCoredDSTs
WASATCH0 ft.

Formation WSTC                     Formation Classification:  GW                     Status:  PR - 8/28/1987

 Completed Information for Formation WASATCH
1st Production Date:12/1/1987Choke Size:0.000 in.
Formation Name:WASATCHCommingled:
Production Method:
Open Hole Completion:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation WSTC.
No Perforation Data was found for formation WSTC.
Primary Well Designation:
Low Producing      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingYProduction Period
11/2024 - 10/2025

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
November 2024 - October 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)3524
GOR
GOR DeterminationMCFE
Average BOE per Day1.666
Average MCFE per Day9.658

 Federal Financial Assurance  i Y

 Tribal Well  i No
