Wellbore #00 Wellbore Classification: GW Status: PR - 1/1/2020 Measured TD: 8230 ft. Vertical TD: 0 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 1/1/2020 | | Wellbore Permit | | | Permit #: | 20022356 | Expiration Date: | 1/12/2004 | | Proposed Top PZ Location: | Sec:20 Twp: 6S 92W | Footage: 1586 FSL 1739 FWL | | Bottom Hole Location: | Sec:20 Twp: 6S 92W | Footage: 1586 FSL 1739 FWL | | Proposed Depth/Form: | 8230 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: MVRD , Formation: MESAVERDE , Order: 0 , Unit Acreage: 640, Drill Unit: ALL | | Formation And Spacing: | Code: RLNS , Formation: ROLLINS , Order: , Unit Acreage: , Drill Unit: | | Casing: | String Type: SURF, Hole Size: 13.75 in., Size: 9.625 in., Top: , Depth: 360 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 1600, Top: 0 ft., Bottom: 3360 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: , Depth: 8229 ft., Weight: 26 , Citings Type: PLANNED | | Cement: | Sacks: 950, Top: 5200 ft., Bottom: 8229 ft. |
| | |
| Wellbore Completed | | Completion Date: | 6/21/1982 | | Measured TD: | 8230 ft. | Measured PB depth: | 7700 ft. | | True Vertical TD: | 0 ft. | True Vertical PB depth: | | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: , Citings Type: HISTORICAL | | Cement: | Sacks: 0, Top: 0 ft., Bottom: , Determination Method: | | Casing: | String Type: SURF, Hole Size: 13.75 in., Size: 9.625 in., Top: 0 ft., Depth: 3360 ft., Weight: , Citings Type: HISTORICAL | | Cement: | Sacks: 0, Top: 0 ft., Bottom: , Determination Method: | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 8229 ft., Weight: , Citings Type: HISTORICAL | | Cement: | Sacks: 0, Top: 0 ft., Bottom: , Determination Method: | | Formation | Interval Top | Log Bottom | Cored | DSTs | | MESAVERDE | 5866 ft. | | | | | ROLLINS | 7096 ft. | | | | | COZZETTE | 7664 ft. | | | | | CORCORAN | 7903 ft. | | | | | MANCOS | 8132 ft. | | | |
Formation WMFK Formation Classification: GW Status: PR - 1/1/2020| Completed Information for Formation WILLIAMS FORK | | 1st Production Date: | 1/10/1993 | Choke Size: | 20,000.000 in. | | Formation Name: | WILLIAMS FORK | Commingled: | | | Production Method: | | | Open Hole Completion: | |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation WMFK. |
| | No Perforation Data was found for formation WMFK. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | Y | Production Period
11/2024 - 10/2025 |
| Total Oil Produced (Barrels) | 0 |
| Total Gas Produced (MCF) | 806 |
| GOR | |
| GOR Determination | MCFE |
| Average BOE per Day | 0.383 |
| Average MCFE per Day | 2.206 |
| Federal Financial Assurance | i | |
|
|
