Wellbore #00 Wellbore Classification: DSPW Status: PA - 2/28/2014 Measured TD: 8733 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: DSPW PA - 2/28/2014 | | Wellbore Permit | | | Permit #: | 110001 | Expiration Date: | 8/20/1959 | | Proposed Depth/Form: | | | Surface Mineral Owner Same: | Not available | | Mineral Owner: | FEE | Surface Owner: | Not available | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: MVRD , Formation: MESAVERDE , Order: 0 , Unit Acreage: 52678, Drill Unit: U |
| | |
| Wellbore Completed | | Completion Date: | 7/21/2005 | | Spud Date: | 4/28/1959 | Spud Date Is: | ACTUAL | | Measured TD: | 8733 ft. | Measured PB depth: | 8720 ft. | | True Vertical TD: | | True Vertical PB depth: | | | Log Types: | | | Casing: | String Type: SURF, Hole Size: 12.5 in., Size: 10.75 in., Top: , Depth: 785 ft., Weight: 40.5 , Citings Type: ACTUAL | | Cement: | Sacks: 700, Top: 0 ft., Bottom: 785 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: , Top: , Depth: 8733 ft., Weight: 23 , Citings Type: ACTUAL | | Cement: | Sacks: 700, Top: 5210 ft., Bottom: 8733 ft., Determination Method: CBL | | Casing: | String Type: 2ND, Hole Size: , Size: , Top: , Depth: 8710 ft., Weight: 15 , Citings Type: ACTUAL | | Cement: | Sacks: 720, Top: 180 ft., Bottom: 8710 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH | 0 ft. | 4707 ft. | N | N | | FORT UNION | 240 ft. | | | | | MESAVERDE | 4004 ft. | | | | | WILLIAMS FORK | 4708 ft. | 7628 ft. | N | N | | ROLLINS | 7629 ft. | 8155 ft. | N | N | | COZZETTE | 8156 ft. | 8436 ft. | N | N | | CORCORAN | 8473 ft. | 8733 ft. | N | N | | MANCOS | 8608 ft. | | | |
Formation CRCRN Formation Classification: GW Status: AB - 2/28/2014 Interval Top: 8424 ft. Interval Bottom: 8626 ft.| Completed Information for Formation CORCORAN | | 1st Production Date: | 7/21/2005 | Choke Size: | | | Formation Name: | CORCORAN | Commingled: | Yes | | Production Method: | INJECTION | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Date: | 7/21/2005 | | Treatment Summary: | STAGE 1 WAS TREATED WITH 3435 BBLS OF LIGHTINING 28 FRAC FLUID AND 400,889# OF 20-40 SAND. |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8137 ft. | | Tubing Packer Depth: | 8137 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CRCRN. |
| | Perforation Data: | | Interval Top: | 8424 ft. | # Of Holes: | 192 | | Interval Bottom: | 8626 ft. | Hole Size: | 0.34 in. |
|
Formation COZZ Formation Classification: GW Status: AB - 2/28/2014 Interval Top: 8200 ft. Interval Bottom: 8366 ft.| Completed Information for Formation COZZETTE | | 1st Production Date: | 7/21/2005 | Choke Size: | | | Formation Name: | COZZETTE | Commingled: | Yes | | Production Method: | INJECTION | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Date: | 7/21/2005 | | Treatment Summary: | STAGE 2 WAS TREATED WIHT 2973 BBLS LIGHTNING 28 FRAC FLLUID AND 349,758# OF 20-40 SAND. |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8137 ft. | | Tubing Packer Depth: | 8137 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation COZZ. |
| | Perforation Data: | | Interval Top: | 8200 ft. | # Of Holes: | 150 | | Interval Bottom: | 8366 ft. | Hole Size: | 0.34 in. |
|
Formation MVRD Formation Classification: GW Status: AB - 1/29/1974 Interval Top: 6778 ft. Interval Bottom: 6924 ft.| Completed Information for Formation MESAVERDE | | 1st Production Date: | 8/9/1959 | Choke Size: | 0.000 in. | | Formation Name: | MESAVERDE | Commingled: | | | Production Method: | | | Open Hole Completion: | |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation MVRD. |
| | Perforation Data: | | Interval Top: | 6778 ft. | # Of Holes: | | | Interval Bottom: | 6924 ft. | Hole Size: | |
|
Formation WMFK Formation Classification: GW Status: AB - 6/16/2005 Interval Top: 6322 ft. Interval Bottom: 6556 ft.| Completed Information for Formation WILLIAMS FORK | | 1st Production Date: | 1/29/1974 | Choke Size: | | | Formation Name: | WILLIAMS FORK | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Date: | 7/21/2005 | | Treatment Summary: | FRAC W 25,000 GAL KCL PAD, FOLLOWED W/ 135,000 GAL GELLED WATER WITH 230,000# SAND, FOLLOWED W/ 11,700 GAL KC1 WATER |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation WMFK. |
| | Perforation Data: | | Interval Top: | 6322 ft. | # Of Holes: | | | Interval Bottom: | 6556 ft. | Hole Size: | |
|
|
|
|
|
|
|
| Reported Plugged | Y | 02/28/2014 |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 0 |
| Total Gas Produced (MCF) | 0 |
| GOR | |
| GOR Determination | |
| Average BOE per Day | 0.000 |
| Average MCFE per Day | 0.000 |
| Federal Financial Assurance | i | |
|
|
