Wellbore #00 Wellbore Classification: OW Status: PR - 10/13/2019 Measured TD: 18653 ft. Vertical TD: 7795 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 10/13/2019 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 8/22/2020 | | Proposed Top PZ Location: | Sec:3 Twp: 1S 68W | Footage: 150 FSL 1475 FEL | | Bottom Hole Location: | Sec:34 Twp: 1N 68W | Footage: 460 FNL 1017 FEL | | Proposed Depth/Form: | 18680 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-2222 , Unit Acreage: 640, Drill Unit: E2 S.3, E2 S.34 | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 42 , Citings Type: PLANNED | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 400, Top: 0 ft., Bottom: 1500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18680 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2503, Top: 1500 ft., Bottom: 18680 ft. |
| | |
| Wellbore Completed | | Completion Date: | 5/25/2019 | | Spud Date: | 3/30/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 18653 ft. | Measured PB depth: | 18638 ft. | | True Vertical TD: | 7795 ft. | True Vertical PB depth: | 7795 ft. | | Top PZ Location: | Sec:3 Twp: 1S 68W | Footage: 188 FSL 1488 FEL | | Bottom Hole Location: | Sec:34 Twp: 1N 68W | Footage: 500 FNL 1001 FEL | | Log Types: | CBL, Mud, MWD/LWD, (Resistivity on 014-20846). | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 80 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1640 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 550, Top: 0 ft., Bottom: 1641 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18643 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2932, Top: 2000 ft., Bottom: 18653 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 5114 ft. | | N | N | | SUSSEX | 5500 ft. | | N | N | | SHANNON | 6090 ft. | | N | N | | SHARON SPRINGS | 8455 ft. | | N | N | | NIOBRARA | 8519 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 10/13/2019 Interval Top: 9028 ft. Interval Bottom: 18628 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 10/4/2019 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 7/29/2019 | Treatment End Date: | 8/7/2019 | | Treatment Summary: | Frac'd Niobrara with 48-stage plug-and-perf;
228213 total bbls fluid pumped: 208635 bbls gelled fluid and 19578 bbls fresh water;
9600045 total lbs proppant pumped: 4800310 lbs 40/70 mesh and 4799735 lbs 30/50 mesh. | | Total fluid used in treatment (bbls): | 228213 | Max pressure during treatment (psi): | 9301 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 48 | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | 0.83 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 7650 | | Fresh water used in treatment (bbls): | 19578 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 9600045 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8864 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 10/13/2019 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 373 | | BBLS_OIL | 319 | | BTU_GAS | 1300 | | CALC_BBLS_H2O | 373 | | CALC_BBLS_OIL | 319 | | CALC_GOR | 1809 | | CALC_MCF_GAS | 577 | | CASING_PRESS | 2407 | | GRAVITY_OIL | 49 | | MCF_GAS | 577 | | TUBING_PRESS | 1804 |
| | Perforation Data: | | Interval Top: | 9028 ft. | # Of Holes: | 1129 | | Interval Bottom: | 18628 ft. | Hole Size: | 0.38 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 4198 |
| Total Gas Produced (MCF) | 99521 |
| GOR | 23706 |
| GOR Determination | MCFE |
| Average BOE per Day | 58.570 |
| Average MCFE per Day | 339.683 |
| Federal Financial Assurance | i | |
|
|
