COGIS - WELL SCOUT CARD

Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-005-07484
Well Classification: OW Status: PR - 4/1/2024
Well Name/No:Eastern Hills 4-65 17-18 #1FH
(Click Well Name for Production Data)
Click Here for Transporter Gatherer Info
Operator:CRESTONE PEAK RESOURCES OPERATING LLC - 10633
(Click Operator Name for Company Detail Report)
Federal Or State Lease #:
Facility Status:PRStatus Date4/1/2024
FacilityID:478055LocationID:474845
Municipality/County:AURORA / ARAPAHOE #005Location:NESE 17 4S65W 6
Field:DJ HORIZONTAL NIOBRARA - #16950Elevation:5640 ft.
Planned Location:1355FSL  700 FELLat/Long: 39.700261 / -104.680888Lat/Long Source: Field Measured

FracFocus
Disclosure: Sidetrack #00
Start Date: 11/13/2022
End Date: 12/12/2022
Reported: 1/26/2023
Days to report: 45
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PR - 4/1/2024             Measured TD: 23818 ft.    Vertical TD: 8106 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PR - 4/1/2024
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:3/7/2025
Proposed Top PZ Location:Sec:17 Twp: 4S 65W Footage: 1100 FNL  460 FEL
Bottom Hole Location:Sec:13 Twp: 4S 66W Footage: 1100 FNL  460 FWL
Proposed Depth/Form:23826 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: 535-1367 , Unit Acreage: 5200, Drill Unit: T4S R65W Secs. 17-20
Casing:String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 100 ft., Weight: 42.09 , Citings Type: PLANNED
Cement:Sacks: 114, Top: 0 ft., Bottom: 100 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3325 ft., Weight: 40 , Citings Type: PLANNED
Cement:Sacks: 1108, Top: 0 ft., Bottom: 3325 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23826 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 3677, Top: , Bottom: 23826 ft.

Wellbore Completed
Completion Date:6/16/2022
Spud Date:5/16/2022Spud Date Is:ACTUAL
Measured TD:23818 ft.Measured PB depth:23817 ft.
True Vertical TD:8106 ft.True Vertical PB depth:8106 ft.
Top PZ Location:Sec:17 Twp: 4S 65WFootage: 1126 FNL  470 FEL
Bottom Hole Location:Sec:13 Twp: 4S 66WFootage: 1100 FNL  461 FWL
Log Types:CBL, MWD/LWD, (Resistivity on 005-07483).
Casing:String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 115 ft., Weight: 42 , Citings Type: ACTUAL
Cement:Sacks: 120, Top: 0 ft., Bottom: 115 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3478 ft., Weight: 40 , Citings Type: ACTUAL
Cement:Sacks: 1145, Top: 0 ft., Bottom: 3478 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23817 ft., Weight: 17 , Citings Type: ACTUAL
Cement:Sacks: 3700, Top: 0 ft., Bottom: 23817 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
PARKMAN4284 ft.NN
SUSSEX5625 ft.NN
SHANNON6637 ft.NN
SHARON SPRINGS8286 ft.NN
NIOBRARA8350 ft.NN

Formation NBRR                     Formation Classification:  OW                     Status:  PR - 4/1/2024                  Interval Top: 8846 ft.    Interval Bottom: 23769 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:3/16/2023Choke Size:
Formation Name:NIOBRARACommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:11/13/2022Treatment End Date:12/12/2022
Treatment Summary:Frac'd Niobrara with 87 stage plug and perf; 17064876 total pounds proppant pumped: 15604121 pounds 40/70 mesh and 1460755 pounds 100 mesh; 770342 total bbls fluid pumped: 685361 bbls gelled fluid, 78717 bbls fresh water and 6264 bbls 15% HCl acid.
Total fluid used in treatment (bbls):770342Max pressure during treatment (psi):8504
Total gas used in treatment (mcf):0Fluid density (lbs/gal):8.30
Type Of gas:Number Of staged intervals:87
Total acid used in treatment (bbls):6264Min frac gradient (psi/ft):0.62
Recycled water used in treatment (bbls):0Total flowback volume recovered (bbls):0
Fresh water used in treatment (bbls):78717Disposition method For flowback:DISPOSAL
Total proppant used (lbs):17064876Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:2.375 in.Tubing Setting Depth:5916 ft.
Tubing Packer Depth:5914 ft.Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:3/26/2023Test Method:FLOWING
Hours Tested:24Gas Type:WET
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 570
BBLS_OIL 433
BTU_GAS 1300
CALC_BBLS_H2O 570
CALC_BBLS_OIL 433
CALC_GOR 991
CALC_MCF_GAS 429
CASING_PRESS 1996
GRAVITY_OIL 42
MCF_GAS 429
TUBING_PRESS 2332
Perforation Data:
Interval Top:8846 ft.# Of Holes:3828
Interval Bottom:23769 ft.Hole Size:0.35 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
May 2024 - April 2025i
Total Oil Produced (Barrels)132167
Total Gas Produced (MCF)406999
GOR3079
GOR DeterminationBOE
Average BOE per Day475.105
Average MCFE per Day2755.624

 Federal Financial Assurance  i

 Tribal Well  i No
