Wellbore #00 Wellbore Classification: OW Status: PR - 3/26/2023 Measured TD: 23568 ft. Vertical TD: 8073 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/26/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 3/7/2025 | | Proposed Top PZ Location: | Sec:17 Twp: 4S 65W | Footage: 1700 FNL 460 FEL | | Bottom Hole Location: | Sec:13 Twp: 4S 66W | Footage: 1700 FNL 460 FWL | | Proposed Depth/Form: | 23577 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-1367 , Unit Acreage: 5200, Drill Unit: T4S R65W Secs. 17-20 | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 100 ft., Weight: 42.09 , Citings Type: PLANNED | | Cement: | Sacks: 114, Top: 0 ft., Bottom: 100 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3285 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 1095, Top: 0 ft., Bottom: 3285 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23577 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 3641, Top: , Bottom: 23577 ft. |
| | |
| Wellbore Completed | | Completion Date: | 6/23/2022 | | Spud Date: | 5/18/2022 | Spud Date Is: | ACTUAL | | Measured TD: | 23568 ft. | Measured PB depth: | 23567 ft. | | True Vertical TD: | 8073 ft. | True Vertical PB depth: | 8073 ft. | | Top PZ Location: | Sec:17 Twp: 4S 65W | Footage: 1718 FNL 470 FEL | | Bottom Hole Location: | Sec:13 Twp: 4S 66W | Footage: 1681 FNL 460 FWL | | Log Types: | CBL, MWD/LWD, (Resistivity on 005-07483). | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 115 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 120, Top: 0 ft., Bottom: 115 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3458 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 1145, Top: 0 ft., Bottom: 3458 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23567 ft., Weight: 17 , Citings Type: ACTUAL | | Cement: | Sacks: 3785, Top: 0 ft., Bottom: 23567 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4171 ft. | | N | N | | SUSSEX | 5495 ft. | | N | N | | SHANNON | 6425 ft. | | N | N | | SHARON SPRINGS | 8141 ft. | | N | N | | NIOBRARA | 8207 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 3/26/2023 Interval Top: 8591 ft. Interval Bottom: 23499 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/17/2023 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 9/18/2022 | Treatment End Date: | 10/3/2022 | | Treatment Summary: | Frac'd Niobrara with 86 stage plug and perf;
17114507 total pounds proppant pumped: 15678051 pounds 40/70 mesh and 1436456 pounds 100 mesh;
747313 total bbls fluid pumped: 688555 bbls gelled fluid, 52592 bbls fresh water and 6166 bbls 15% HCl acid. | | Total fluid used in treatment (bbls): | 747313 | Max pressure during treatment (psi): | 9294 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 86 | | Total acid used in treatment (bbls): | 6166 | Min frac gradient (psi/ft): | 0.90 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 0 | | Fresh water used in treatment (bbls): | 52592 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 17114507 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8177 ft. | | Tubing Packer Depth: | 8174 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/26/2023 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 992 | | BBLS_OIL | 915 | | BTU_GAS | 1300 | | CALC_BBLS_H2O | 992 | | CALC_BBLS_OIL | 915 | | CALC_GOR | 1094 | | CALC_MCF_GAS | 1001 | | CASING_PRESS | 1477 | | GRAVITY_OIL | 42 | | MCF_GAS | 1001 | | TUBING_PRESS | 1907 |
| | Perforation Data: | | Interval Top: | 8591 ft. | # Of Holes: | 3784 | | Interval Bottom: | 23499 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 44270 |
| Total Gas Produced (MCF) | 221575 |
| GOR | 5005 |
| GOR Determination | BOE |
| Average BOE per Day | 225.965 |
| Average MCFE per Day | 1310.607 |
| Federal Financial Assurance | i | |
|
|
