Wellbore #00 Wellbore Classification: OW Status: PR - 4/28/2023 Measured TD: 23340 ft. Vertical TD: 8141 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 4/28/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 3/7/2025 | | Proposed Top PZ Location: | Sec:20 Twp: 4S 65W | Footage: 930 FNL 460 FEL | | Bottom Hole Location: | Sec:24 Twp: 4S 66W | Footage: 930 FNL 460 FWL | | Proposed Depth/Form: | 23307 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-1367 , Unit Acreage: 5200, Drill Unit: T4S R65W Secs. 17-20 | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 100 ft., Weight: 42.09 , Citings Type: PLANNED | | Cement: | Sacks: 114, Top: 0 ft., Bottom: 100 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2281 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 1163, Top: 0 ft., Bottom: 2281 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23307 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 3578, Top: , Bottom: 23307 ft. |
| | |
| Wellbore Completed | | Completion Date: | 5/1/2022 | | Spud Date: | 9/19/2021 | Spud Date Is: | ACTUAL | | Measured TD: | 23340 ft. | Measured PB depth: | 23327 ft. | | True Vertical TD: | 8141 ft. | True Vertical PB depth: | 8141 ft. | | Top PZ Location: | Sec:20 Twp: 4S 65W | Footage: 905 FNL 470 FEL | | Bottom Hole Location: | Sec:24 Twp: 4S 66W | Footage: 919 FNL 459 FWL | | Log Types: | CBL, MWD/LWD, (Resistivity on 005-07471). | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 105 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 115, Top: 0 ft., Bottom: 105 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2290 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 1154, Top: 0 ft., Bottom: 2290 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23327 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 3720, Top: 100 ft., Bottom: 23327 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4061 ft. | | N | N | | SUSSEX | 5321 ft. | | N | N | | SHANNON | 6206 ft. | | N | N | | SHARON SPRINGS | 7836 ft. | | N | N | | NIOBRARA | 7899 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 4/1/2023 Interval Top: 8361 ft. Interval Bottom: 23279 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/23/2023 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 12/19/2022 | Treatment End Date: | 1/28/2023 | | Treatment Summary: | Frac'd Niobrara with 85 stage plug and perf;
17203529 total pounds proppant pumped: 15662471 pounds 40/70 mesh and 1541058 pounds 100 mesh;
735390 total bbls fluid pumped: 687430 bbls gelled fluid, 41889 bbls fresh water and 6071 bbls 15% HCl acid. | | Total fluid used in treatment (bbls): | 735390 | Max pressure during treatment (psi): | 8876 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 85 | | Total acid used in treatment (bbls): | 6071 | Min frac gradient (psi/ft): | 0.91 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 0 | | Fresh water used in treatment (bbls): | 41889 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 17203529 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8087 ft. | | Tubing Packer Depth: | 8084 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/1/2023 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 1071 | | BBLS_OIL | 863 | | BTU_GAS | 1300 | | CALC_BBLS_H2O | 1071 | | CALC_BBLS_OIL | 863 | | CALC_GOR | 918 | | CALC_MCF_GAS | 792 | | CASING_PRESS | 1933 | | GRAVITY_OIL | 42 | | MCF_GAS | 792 | | TUBING_PRESS | 2278 |
| | Perforation Data: | | Interval Top: | 8361 ft. | # Of Holes: | 3740 | | Interval Bottom: | 23279 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 35057 |
| Total Gas Produced (MCF) | 222475 |
| GOR | 6346 |
| GOR Determination | BOE |
| Average BOE per Day | 201.404 |
| Average MCFE per Day | 1168.102 |
