Wellbore #00 Wellbore Classification: OW Status: PR - 2/1/2023 Measured TD: 18088 ft. Vertical TD: 7836 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 2/1/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 1/12/2023 | | Proposed Top PZ Location: | Sec:21 Twp: 4S 65W | Footage: 491 FNL 470 FWL | | Bottom Hole Location: | Sec:22 Twp: 4S 65W | Footage: 506 FNL 468 FEL | | Proposed Depth/Form: | 18011 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-1342 , Unit Acreage: 1280, Drill Unit: Sec. 21 & 22: All | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 99 ft., Weight: 42.09 , Citings Type: PLANNED | | Cement: | Sacks: 86, Top: 0 ft., Bottom: 99 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2272 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 1223, Top: 0 ft., Bottom: 2272 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18011 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2616, Top: , Bottom: 18011 ft. |
| | |
| Wellbore Completed | | Completion Date: | 10/17/2021 | | Spud Date: | 9/18/2021 | Spud Date Is: | ACTUAL | | Measured TD: | 18088 ft. | Measured PB depth: | 18068 ft. | | True Vertical TD: | 7836 ft. | True Vertical PB depth: | 7836 ft. | | Top PZ Location: | Sec:21 Twp: 4S 65W | Footage: 491 FNL 470 FWL | | Bottom Hole Location: | Sec:22 Twp: 4S 65W | Footage: 506 FNL 468 FEL | | Log Types: | CBL, MWD/LWD, IND-DENS-NEU. | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 104 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 104 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2299 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 1165, Top: 0 ft., Bottom: 2299 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18068 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2175, Top: 1360 ft., Bottom: 18068 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 5391 ft. | | N | N | | SHANNON | 6278 ft. | | N | N | | SHARON SPRINGS | 7911 ft. | | N | N | | NIOBRARA | 8086 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 2/1/2023 Interval Top: 8460 ft. Interval Bottom: 17959 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/21/2022 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 1/29/2022 | Treatment End Date: | 2/16/2022 | | Treatment Summary: | Frac'd Niobrara with 52 stage plug and perf:
10460385 total lbs proppant pumped: 10069595 lbs 40/70 mesh and 390790 lbs 100 mesh.
434311 total bbls fluid pumped: 416894 bbls gelled fluid, 13739 bbls fresh water, and 3678 bbls 15% HCl acid. | | Total fluid used in treatment (bbls): | 434311 | Max pressure during treatment (psi): | 8760 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 52 | | Total acid used in treatment (bbls): | 3678 | Min frac gradient (psi/ft): | 0.86 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 2258 | | Fresh water used in treatment (bbls): | 13739 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 10460385 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8252 ft. | | Tubing Packer Depth: | 8250 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/10/2022 | Test Method: | flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 382 | | BBLS_OIL | 82 | | BTU_GAS | 1387 | | CALC_BBLS_H2O | 382 | | CALC_BBLS_OIL | 82 | | CALC_GOR | 2817 | | CALC_MCF_GAS | 231 | | CASING_PRESS | 1950 | | GRAVITY_OIL | 43 | | MCF_GAS | 231 | | TUBING_PRESS | 2350 |
| | Perforation Data: | | Interval Top: | 8460 ft. | # Of Holes: | 2260 | | Interval Bottom: | 17959 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 25461 |
| Total Gas Produced (MCF) | 91842 |
| GOR | 3607 |
| GOR Determination | BOE |
| Average BOE per Day | 112.990 |
| Average MCFE per Day | 655.357 |
| Federal Financial Assurance | i | |
|
|
