Wellbore #00 Wellbore Classification: OW Status: PR - 2/14/2022 Measured TD: 18432 ft. Vertical TD: 7883 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 2/14/2022 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 12/30/2022 | | Proposed Top PZ Location: | Sec:28 Twp: 4S 65W | Footage: 1140 FNL 330 FWL | | Bottom Hole Location: | Sec:27 Twp: 4S 65W | Footage: 900 FNL 330 FEL | | Proposed Depth/Form: | 18442 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-1255 , Unit Acreage: 1280, Drill Unit: Sec 27 & 28 | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 99 ft., Weight: 42 , Citings Type: PLANNED | | Cement: | Sacks: 86, Top: 0 ft., Bottom: 99 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2337 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 1257, Top: 0 ft., Bottom: 23337 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18442 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2686, Top: , Bottom: 18442 ft. |
| | |
| Wellbore Completed | | Completion Date: | 8/22/2021 | | Spud Date: | 6/14/2021 | Spud Date Is: | ACTUAL | | Measured TD: | 18432 ft. | Measured PB depth: | 18405 ft. | | True Vertical TD: | 7883 ft. | True Vertical PB depth: | 7883 ft. | | Top PZ Location: | Sec:28 Twp: 4S 65W | Footage: 1173 FNL 341 FWL | | Bottom Hole Location: | Sec:27 Twp: 4S 65W | Footage: 900 FNL 337 FEL | | Log Types: | Mud, MWD/LWD, CBL, (Open Hole log on 005-07468). | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 104 ft., Weight: 42.09 , Citings Type: ACTUAL | | Cement: | Sacks: 52, Top: 0 ft., Bottom: 104 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2367 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 1250, Top: 0 ft., Bottom: 2367 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18418 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2658, Top: 2390 ft., Bottom: 18418 ft., Determination Method: CBL | | Additional Cement: | String Type: SURF , Top: 44 ft., Depth: 81 ft., Bottom: 81 ft., Sacks: 19, Method: 1 INCH | | Additional Cement: | String Type: SURF , Top: 0 ft., Depth: 44 ft., Bottom: 44 ft., Sacks: 14, Method: 1 INCH | | Formation | Interval Top | Log Bottom | Cored | DSTs | | DENVER | 24 ft. | 1425 ft. | N | N | | LARAMIE | 1425 ft. | 1774 ft. | N | N | | FOX HILLS | 1774 ft. | 1996 ft. | N | N | | PIERRE | 1996 ft. | 8020 ft. | N | N | | NIOBRARA | 8020 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 2/14/2022 Interval Top: 8515 ft. Interval Bottom: 18309 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 1/28/2022 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 11/26/2021 | Treatment End Date: | 12/6/2021 | | Treatment Summary: | Frac'd Niobrara with 57 stage plug and perf:
11105180 total pounds proppant pumped: 10691030 pounds 40/70 mesh; 414150 pounds 100 mesh.
458438 total bbls fluid pumped: 436684 bbls gelled fluid; 17708 bbls fresh water and 4046 bbls 15% HCl Acid. | | Total fluid used in treatment (bbls): | 458438 | Max pressure during treatment (psi): | 9130 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 57 | | Total acid used in treatment (bbls): | 4046 | Min frac gradient (psi/ft): | 0.87 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 781 | | Fresh water used in treatment (bbls): | 17708 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 11105180 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8326 ft. | | Tubing Packer Depth: | 8330 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 2/14/2022 | Test Method: | flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 302 | | BBLS_OIL | 278 | | BTU_GAS | 1394 | | CALC_BBLS_H2O | 302 | | CALC_BBLS_OIL | 278 | | CALC_GOR | 910 | | CALC_MCF_GAS | 253 | | CASING_PRESS | 1950 | | GRAVITY_OIL | 40 | | MCF_GAS | 253 | | TUBING_PRESS | 2000 |
| | Perforation Data: | | Interval Top: | 8515 ft. | # Of Holes: | 2480 | | Interval Bottom: | 18309 ft. | Hole Size: | 0.3 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 25476 |
| Total Gas Produced (MCF) | 112111 |
| GOR | 4400 |
| GOR Determination | BOE |
| Average BOE per Day | 122.965 |
| Average MCFE per Day | 713.209 |
| Federal Financial Assurance | i | |
|
|
