Wellbore #00 Wellbore Classification: OW Status: PR - 8/1/2025 Measured TD: 17906 ft. Vertical TD: 7709 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 8/1/2025 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 8/12/2020 | | Proposed Top PZ Location: | Sec:11 Twp: 4S 65W | Footage: 1824 FSL 825 FWL | | Bottom Hole Location: | Sec:12 Twp: 4S 65W | Footage: 1874 FSL 329 FEL | | Proposed Depth/Form: | 17867 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-905 , Unit Acreage: 1280, Drill Unit: SEC 11 & 12 ALL | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 100 ft., Weight: 65 , Citings Type: PLANNED | | Cement: | Sacks: , Top: 0 ft., Bottom: 100 ft. | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 2149 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 590, Top: 0 ft., Bottom: 2149 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17867 ft., Weight: 23 , Citings Type: PLANNED | | Cement: | Sacks: 2240, Top: 2149 ft., Bottom: 17867 ft. |
| | |
| Wellbore Completed | | Completion Date: | 3/12/2019 | | Spud Date: | 2/18/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 17906 ft. | Measured PB depth: | 17822 ft. | | True Vertical TD: | 7709 ft. | True Vertical PB depth: | 7710 ft. | | Top PZ Location: | Sec:11 Twp: 4S 65W | Footage: 1824 FSL 825 FWL | | Bottom Hole Location: | Sec:12 Twp: 4S 65W | Footage: 1874 FSL 329 FEL | | Log Types: | MWD/LWD; Mud Log; CBL; (Resistivity in API 005-07384) | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 100 ft., Weight: 65 , Citings Type: ACTUAL | | Cement: | Sacks: , Top: 0 ft., Bottom: 100 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2179 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 745, Top: 0 ft., Bottom: 2190 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17898 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2325, Top: 1000 ft., Bottom: 17906 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | FOX HILLS | 1743 ft. | | | | | PIERRE | 1953 ft. | | | | | SUSSEX | 7251 ft. | | | | | SHANNON | 7567 ft. | | | | | SHARON SPRINGS | 7801 ft. | | | | | NIOBRARA | 7899 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 8/1/2025 Interval Top: 8475 ft. Interval Bottom: 17767 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 12/6/2019 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 7/24/2019 | Treatment End Date: | 8/14/2019 | | Treatment Summary: | 1928 bbls 15% HCI Acid; 314 bbls Fresh Water; 6180 bbls Wireline Pump In; 119397 bbls FR Water; 38590 bbls HVFR; 644449 lbs 100 Mesh; 5824740 lbs 40/70 white. | | Total fluid used in treatment (bbls): | 166409 | Max pressure during treatment (psi): | 9148 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 27 | | Total acid used in treatment (bbls): | 1928 | Min frac gradient (psi/ft): | 0.91 | | Recycled water used in treatment (bbls): | 6180 | Total flowback volume recovered (bbls): | 12591 | | Fresh water used in treatment (bbls): | 158301 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 6469189 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.875 in. | Tubing Setting Depth: | 7770 ft. | | Tubing Packer Depth: | 7520 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 11/6/2019 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 384 | | BBLS_OIL | 1126 | | CALC_BBLS_H2O | 384 | | CALC_BBLS_OIL | 1126 | | CALC_GOR | 1009 | | CALC_MCF_GAS | 1137 | | CASING_PRESS | 1 | | GRAVITY_OIL | 39 | | MCF_GAS | 1137 | | TUBING_PRESS | 959 |
| | Perforation Data: | | Interval Top: | 8475 ft. | # Of Holes: | 266 | | Interval Bottom: | 17767 ft. | Hole Size: | 0.38 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 10997 |
| Total Gas Produced (MCF) | 6676 |
| GOR | 607 |
| GOR Determination | BOE |
| Average BOE per Day | 33.336 |
| Average MCFE per Day | 193.335 |
| Federal Financial Assurance | i | |
|
|
