Wellbore #00 Wellbore Classification: OW Status: PR - 8/1/2024 Measured TD: 17768 ft. Vertical TD: 7415 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 8/1/2024 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 9/14/2024 | | Proposed Top PZ Location: | Sec:3 Twp: 4S 64W | Footage: 1370 FSL 330 FWL | | Bottom Hole Location: | Sec:2 Twp: 4S 64W | Footage: 1370 FSL 330 FEL | | Proposed Depth/Form: | 17939 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-1355 , Unit Acreage: 1280, Drill Unit: T4S R64W Sec. 2 & 3: | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 100 ft., Weight: 42.09 , Citings Type: PLANNED | | Cement: | Sacks: 114, Top: 0 ft., Bottom: 100 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3024 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 1617, Top: 0 ft., Bottom: 3024 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17939 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2489, Top: , Bottom: 17939 ft. |
| | |
| Wellbore Completed | | Completion Date: | 12/2/2021 | | Spud Date: | 10/28/2021 | Spud Date Is: | ACTUAL | | Measured TD: | 17768 ft. | Measured PB depth: | 17761 ft. | | True Vertical TD: | 7415 ft. | True Vertical PB depth: | 7415 ft. | | Top PZ Location: | Sec:3 Twp: 4S 64W | Footage: 1420 FSL 341 FWL | | Bottom Hole Location: | Sec:2 Twp: 4S 64W | Footage: 1405 FSL 440 FEL | | Log Types: | CBL, MUD, MWD, (COMPOSITE 005-07360) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 100 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 115, Top: 0 ft., Bottom: 100 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3098 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 1530, Top: 0 ft., Bottom: 3098 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17761 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2800, Top: 3292 ft., Bottom: 17761 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 4910 ft. | | N | N | | SHANNON | 5708 ft. | | N | N | | SHARON SPRINGS | 7385 ft. | | N | N | | NIOBRARA | 7467 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 8/1/2024 Interval Top: 7889 ft. Interval Bottom: 17650 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/17/2022 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 1/26/2022 | Treatment End Date: | 2/14/2022 | | Treatment Summary: | Frac'd Niobrara with 55 stage plug and perf:
15296105 total pounds proppant pumped: 14541610 pounds 40/70 mesh; 754495 pounds 100 mesh.
621228 total bbls fluid pumped: 598963 bbls gelled fluid; 18336 bbls fresh water and 3929 bbls 15% HCl Acid.
| | Total fluid used in treatment (bbls): | 621228 | Max pressure during treatment (psi): | 8924 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 55 | | Total acid used in treatment (bbls): | 3929 | Min frac gradient (psi/ft): | 0.83 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 2384 | | Fresh water used in treatment (bbls): | 18336 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 15296105 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7778 ft. | | Tubing Packer Depth: | 7776 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/2/2022 | Test Method: | flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 20 | | BBLS_OIL | 7 | | BTU_GAS | 1337 | | CALC_BBLS_H2O | 20 | | CALC_BBLS_OIL | 7 | | CALC_GOR | 11714 | | CALC_MCF_GAS | 82 | | CASING_PRESS | 1050 | | GRAVITY_OIL | 39 | | MCF_GAS | 82 | | TUBING_PRESS | 1350 |
| | Perforation Data: | | Interval Top: | 7889 ft. | # Of Holes: | 2392 | | Interval Bottom: | 17650 ft. | Hole Size: | 0.26 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 31832 |
| Total Gas Produced (MCF) | 92573 |
| GOR | 2908 |
| GOR Determination | BOE |
| Average BOE per Day | 131.185 |
| Average MCFE per Day | 760.868 |
| Federal Financial Assurance | i | |
|
|
