Wellbore #00 Wellbore Classification: OW Status: PR - 10/5/2023 Measured TD: 18259 ft. Vertical TD: 8025 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 10/5/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 7/8/2020 | | Proposed Top PZ Location: | Sec:4 Twp: 4S 65W | Footage: 1835 FNL 817 FWL | | Bottom Hole Location: | Sec:4 Twp: 4S 65W | Footage: 1835 FNL 817 FWL | | Proposed Depth/Form: | 18316 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-902 , Unit Acreage: 1280, Drill Unit: 5-All & 6-All | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 42 , Citings Type: PLANNED | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 2150 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 575, Top: 0 ft., Bottom: 2150 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18316 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2356, Top: , Bottom: 18316 ft. |
| | |
| Wellbore Completed | | Completion Date: | 1/21/2023 | | Spud Date: | 6/30/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 18259 ft. | Measured PB depth: | 18253 ft. | | True Vertical TD: | 8025 ft. | True Vertical PB depth: | 8025 ft. | | Top PZ Location: | Sec:5 Twp: 4S 65W | Footage: 538 FNL 481 FEL | | Bottom Hole Location: | Sec:6 Twp: 4S 65W | Footage: 516 FNL 461 FWL | | Log Types: | No logs to upload. | | Log Types: | CBL, MWD, (RES 005-07375). | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 53 , Citings Type: ACTUAL | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 80 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 2702 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 1050, Top: 0 ft., Bottom: 2702 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18253 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2880, Top: 0 ft., Bottom: 18253 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4943 ft. | | N | N | | SUSSEX | 5572 ft. | | N | N | | SHANNON | 6374 ft. | | N | N | | SHARON SPRINGS | 8012 ft. | | N | N | | NIOBRARA | 8056 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 10/5/2023 Interval Top: 8590 ft. Interval Bottom: 18202 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 9/21/2023 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 6/23/2023 | Treatment End Date: | 7/13/2023 | | Treatment Summary: | Frac'd Niobrara with 54 stage plug and perf:
11170646 total pounds proppant pumped: 7455490 pounds 40/70 mesh; 3715156 pounds 100 mesh;
468410 total bbls fluid pumped: 441396 bbls gelled fluid; 23145 bbls fresh water and 3869 bbls 15% HCl Acid.
| | Total fluid used in treatment (bbls): | 468410 | Max pressure during treatment (psi): | 8953 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 54 | | Total acid used in treatment (bbls): | 3869 | Min frac gradient (psi/ft): | 0.85 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 0 | | Fresh water used in treatment (bbls): | 23145 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 11170646 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8268 ft. | | Tubing Packer Depth: | 8259 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 10/5/2023 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 454 | | BBLS_OIL | 942 | | BTU_GAS | 1400 | | CALC_BBLS_H2O | 454 | | CALC_BBLS_OIL | 942 | | CALC_GOR | 951 | | CALC_MCF_GAS | 896 | | CASING_PRESS | 1006 | | GRAVITY_OIL | 40 | | MCF_GAS | 896 | | TUBING_PRESS | 1684 |
| | Perforation Data: | | Interval Top: | 8590 ft. | # Of Holes: | 3044 | | Interval Bottom: | 18202 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 66383 |
| Total Gas Produced (MCF) | 111523 |
| GOR | 1679 |
| GOR Determination | BOE |
| Average BOE per Day | 234.524 |
| Average MCFE per Day | 1360.241 |
| Federal Financial Assurance | i | |
|
|
