COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 This operator is no longer active in the State of Colorado.
 Surface Location
 API# 05-005-06211		Well Classification: ERIW Status: PA - 8/29/1989
Well Name/No:PEORIA J-SAND UNIT #3
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PARKER & PARSLEY DEV L P - 67270
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date8/29/1989
FacilityID:204127LocationID:377763
County:ARAPAHOE #005Location:NENW 20 4S60W 6
Field:PEORIA - #68350Elevation:5130 ft.
Basin:DENVER (DJ) BASIN
Planned Location:660FNL  1980 FWLLat/Long: 39.694016 / -104.127796Lat/Long Source: Calculated From Footages
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: ERIW             Status: PA - 8/29/1989             Measured TD: 6575 ft.

 Wellbore Data for Original WellboreWellbore Classification: ERIW        PA - 8/29/1989
Wellbore Permit
Permit #:19710131 Expiration Date:3/1/1972
Proposed Depth/Form:6575 ft.
Surface Mineral Owner Same:Not available
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Wellbore Completed
Completion Date:4/10/1971
Spud Date:3/3/1971Spud Date Is:ACTUAL
Measured TD:6575 ft.Measured PB depth:6466 ft.
True Vertical TD:True Vertical PB depth:
Log Types:INDUCTION ELECTROLOG, ACOUSTILOG
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: , Depth: 712 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 425, Top: , Bottom: , Determination Method:
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: , Depth: 6574 ft., Weight: 9.5 , Citings Type: ACTUAL
Cement:Sacks: 250, Top: , Bottom: , Determination Method:
FormationInterval TopLog BottomCoredDSTs
NIOBRARA5602 ft.N
FORT HAYS5954 ft.N
CARLILE5994 ft.N
GREENHORN6072 ft.N
BENTONITE6295 ft.N
D SAND6391 ft.N
J SAND6440 ft.NY

Formation JSND                     Formation Classification:  GW                     Status:  AB - 8/29/1989                 Interval Top: 6458 ft.    Interval Bottom: 64450 ft.

 Completed Information for Formation J SAND
1st Production Date:N/AChoke Size:
Formation Name:J SANDCommingled:No
Production Method:INJECTION
Open Hole Completion:
Formation Treatment
Treatment Date:4/10/1971
Treatment Summary:SEE SCANNED DOCUMENT# 00424204
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation JSND.
Perforation Data:
Interval Top:6458 ft.# Of Holes:16
Interval Bottom:64450 ft.Hole Size:0.48 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY08/29/1989
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
September 2024 - August 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
