Wellbore #00 Wellbore Classification: OW Status: PR - 4/7/2023 Measured TD: 17660 ft. Vertical TD: 7902 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 4/7/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 6/10/2022 | | Proposed Top PZ Location: | Sec:22 Twp: 1S 67W | Footage: 2531 FNL 859 FEL | | Bottom Hole Location: | Sec:15 Twp: 1S 67W | Footage: 294 FNL 863 FEL | | Proposed Depth/Form: | 17300 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CARL , Formation: CARLILE , Order: 407-3725 , Unit Acreage: 960, Drill Unit: SEC15:ALL SEC22:N2 | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 407-3725 , Unit Acreage: 960, Drill Unit: SEC15:ALL SEC22:N2 | | Formation And Spacing: | Code: FTHYS , Formation: FORT HAYS , Order: 407-3725 , Unit Acreage: 960, Drill Unit: SEC15:ALL SEC22:N2 | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-3725 , Unit Acreage: 960, Drill Unit: SEC15:ALL SEC22:N2 | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1752 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 685, Top: 0 ft., Bottom: 1752 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17300 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 1927, Top: 5286 ft., Bottom: 17300 ft. |
| | |
| Wellbore Completed | | Completion Date: | 3/2/2022 | | Spud Date: | 11/19/2021 | Spud Date Is: | ACTUAL | | Measured TD: | 17660 ft. | Measured PB depth: | 17655 ft. | | True Vertical TD: | 7902 ft. | True Vertical PB depth: | 7902 ft. | | Top PZ Location: | Sec:22 Twp: 1S 67W | Footage: 2531 FNL 859 FEL | | Bottom Hole Location: | Sec:15 Twp: 1S 67W | Footage: 294 FNL 863 FEL | | Log Types: | MWD/LWD, Mud, CBL (Composite in 001-10516) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2043 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 1048, Top: 0 ft., Bottom: 2043 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17660 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 1900, Top: 2086 ft., Bottom: 17660 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 5232 ft. | 5408 ft. | N | N | | SUSSEX | 5735 ft. | 5979 ft. | N | N | | SHANNON | 6655 ft. | 6907 ft. | N | N | | SHARON SPRINGS | 9061 ft. | | N | N | | NIOBRARA | 9235 ft. | | N | N | | FORT HAYS | 9901 ft. | | N | N | | CODELL | 9990 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: CM - 8/28/2024 Interval Top: 12783 ft. Interval Bottom: 14453 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 8/28/2024 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 12,783'-14,453' | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation NBRR. |
| | Perforation Data: | | Interval Top: | 12783 ft. | # Of Holes: | 1438 | | Interval Bottom: | 14453 ft. | Hole Size: | 0.42 in. |
|
Formation FTHYS Formation Classification: OW Status: CM - 8/28/2024 Interval Top: 12133 ft. Interval Bottom: 16606 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 8/28/2024 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 12,133’ – 12,783’, 14,453’ – 14,864’, 16,094’ – 16,606’ | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 12133 ft. | # Of Holes: | 1438 | | Interval Bottom: | 16606 ft. | Hole Size: | 0.42 in. |
|
Formation CODL Formation Classification: OW Status: CM - 8/28/2024 Interval Top: 10187 ft. Interval Bottom: 17482 ft.| Completed Information for Formation CODELL | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 8/28/2024 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 10,187’-12,133’, 14,864’- 16,094’, 16,606’ – 17,482’ | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 10187 ft. | # Of Holes: | 1438 | | Interval Bottom: | 17482 ft. | Hole Size: | 0.42 in. |
|
Formation NBFHC Formation Classification: OW Status: PR - 4/7/2023 Interval Top: 10187 ft. Interval Bottom: 17482 ft.| Completed Information for Formation NIOBRARA-FT HAYS-CODELL | | 1st Production Date: | 3/23/2023 | Choke Size: | | | Formation Name: | NIOBRARA-FT HAYS-CODELL | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 2/12/2023 | Treatment End Date: | 2/22/2023 | | Treatment Summary: | 40 Stage Plug and Perf
Total Fluid: 144,639
Gel Fluid: 77,812 bbls
Slickwater Fluid: 66,335 bbls
15% HCl Acid: 492 bbls
Total Proppant: 8,628,320 lbs
Silica Proppant: 8,628,320 lbs
Method for determining flowback: Measuring flowback tank volumes. | | Total fluid used in treatment (bbls): | 144639 | Max pressure during treatment (psi): | 4797 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 40 | | Total acid used in treatment (bbls): | 492 | Min frac gradient (psi/ft): | 0.90 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 3668 | | Fresh water used in treatment (bbls): | 144147 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 8628320 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 9735 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/7/2023 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 383 | | BBLS_OIL | 433 | | BTU_GAS | 1409 | | CALC_BBLS_H2O | 383 | | CALC_BBLS_OIL | 433 | | CALC_GOR | 1275 | | CALC_MCF_GAS | 552 | | CASING_PRESS | 2017 | | GRAVITY_OIL | 44 | | MCF_GAS | 552 | | TUBING_PRESS | 1604 |
| | Perforation Data: | | Interval Top: | 10187 ft. | # Of Holes: | 1438 | | Interval Bottom: | 17482 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 40771 |
| Total Gas Produced (MCF) | 172509 |
| GOR | 4231 |
| GOR Determination | BOE |
| Average BOE per Day | 193.189 |
| Average MCFE per Day | 1120.496 |
| Federal Financial Assurance | i | |
|
|
