Wellbore #00 Wellbore Classification: OW Status: PR - 3/21/2023 Measured TD: 21272 ft. Vertical TD: 7742 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/21/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 6/10/2022 | | Proposed Top PZ Location: | Sec:22 Twp: 1S 67W | Footage: 2565 FSL 1200 FWL | | Bottom Hole Location: | Sec:34 Twp: 1S 67W | Footage: 370 FSL 1220 FWL | | Proposed Depth/Form: | 21167 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-2793 , Unit Acreage: 1600, Drill Unit: 27&34:ALL SEC22:S2 | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2000 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 844, Top: 0 ft., Bottom: 2000 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 21167 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 3097, Top: , Bottom: 21167 ft. |
| | |
| Wellbore Completed | | Completion Date: | 2/10/2022 | | Spud Date: | 10/25/2021 | Spud Date Is: | ACTUAL | | Measured TD: | 21272 ft. | Measured PB depth: | 21266 ft. | | True Vertical TD: | 7742 ft. | True Vertical PB depth: | 7742 ft. | | Top PZ Location: | Sec:22 Twp: 1S 67W | Footage: 2554 FSL 1198 FWL | | Bottom Hole Location: | Sec:34 Twp: 1S 67W | Footage: 299 FSL 1216 FWL | | Log Types: | MWD/LWD, Mud, CBL (Composite in 001-10516) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2052 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 927, Top: 0 ft., Bottom: 2052 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 21272 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2375, Top: 1875 ft., Bottom: 21272 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4565 ft. | 4720 ft. | N | N | | SUSSEX | 4911 ft. | 5131 ft. | N | N | | SHANNON | 5702 ft. | 5914 ft. | N | N | | SHARON SPRINGS | 7807 ft. | | N | N | | NIOBRARA | 8001 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 3/21/2023 Interval Top: 8491 ft. Interval Bottom: 21099 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/17/2023 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 11/25/2022 | Treatment End Date: | 12/27/2022 | | Treatment Summary: | 69 Stage Plug and Perf
Total Fluid: 271,651 bbls
Gel Fluid: 139,806 bbls
Slickwater Fluid: 130,595 bbls
15% HCl Acid: 1,250 bbls
Total Proppant: 11,354,635 lbs
Silcia Proppant: 11,354,635 lbs
Method for determining flowback: Measuring flowback tank volume. | | Total fluid used in treatment (bbls): | 271651 | Max pressure during treatment (psi): | 4709 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 69 | | Total acid used in treatment (bbls): | 1250 | Min frac gradient (psi/ft): | 0.85 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 17157 | | Fresh water used in treatment (bbls): | 270401 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 11354635 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8135 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/21/2023 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 973 | | BBLS_OIL | 247 | | BTU_GAS | 1409 | | CALC_BBLS_H2O | 973 | | CALC_BBLS_OIL | 247 | | CALC_GOR | 607 | | CALC_MCF_GAS | 150 | | CASING_PRESS | 2433 | | GRAVITY_OIL | 44 | | MCF_GAS | 150 | | TUBING_PRESS | 1532 |
| | Perforation Data: | | Interval Top: | 8491 ft. | # Of Holes: | 2480 | | Interval Bottom: | 21099 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 6220 |
| Total Gas Produced (MCF) | 163755 |
| GOR | 26327 |
| GOR Determination | MCFE |
| Average BOE per Day | 94.406 |
| Average MCFE per Day | 547.569 |
| Federal Financial Assurance | i | |
|
|
