Wellbore #00 Wellbore Classification: OW Status: PR - 4/26/2023 Measured TD: 21771 ft. Vertical TD: 7586 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 4/26/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 4/9/2025 | | Proposed Top PZ Location: | Sec:22 Twp: 1S 67W | Footage: 2540 FSL 1100 FWL | | Bottom Hole Location: | Sec:34 Twp: 1S 67W | Footage: 370 FSL 1120 FWL | | Proposed Depth/Form: | 21696 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 407-2793 , Unit Acreage: 1600, Drill Unit: 27&34:ALL SEC22:S2 | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-2793 , Unit Acreage: 1600, Drill Unit: S 22:S2; S 27 and 34 | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2220 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 937, Top: 0 ft., Bottom: 2220 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 21696 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 3133, Top: , Bottom: 21696 ft. |
| | |
| Wellbore Completed | | Completion Date: | 6/23/2022 | | Spud Date: | 5/27/2022 | Spud Date Is: | ACTUAL | | Measured TD: | 21771 ft. | Measured PB depth: | 21744 ft. | | True Vertical TD: | 7586 ft. | True Vertical PB depth: | 7586 ft. | | Top PZ Location: | Sec:22 Twp: 1S 67W | Footage: 2539 FSL 1650 FEL | | Bottom Hole Location: | Sec:34 Twp: 1S 67W | Footage: 476 FSL 1655 FEL | | Log Types: | CBL, MWD (Composite log in 05-001-10516) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2292 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 1187, Top: 0 ft., Bottom: 2292 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 21758 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2420, Top: 2320 ft., Bottom: 21758 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 5145 ft. | | | | | SUSSEX | 5541 ft. | | | | | SHANNON | 7058 ft. | | | | | SHARON SPRINGS | 8519 ft. | | | | | NIOBRARA | 8742 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 4/26/2023 Interval Top: 9184 ft. Interval Bottom: 21758 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 4/3/2023 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 12/28/2022 | Treatment End Date: | 1/12/2023 | | Treatment Summary: | 36 Stage Plug and Perf
Total Fluid: 196,936 bbls
Gel Fluid: 103,095 bbls
Slickwater Fluid: 93,171 bbls
15% HCl Acid: 670 bbls
Total Proppant: 7,786,485 lbs
Silica Proppant: 7,786,485 lbs
Method for determining flowback: Measuring flowback tank volumes. | | Total fluid used in treatment (bbls): | 196936 | Max pressure during treatment (psi): | 5348 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 36 | | Total acid used in treatment (bbls): | 670 | Min frac gradient (psi/ft): | 0.92 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 25398 | | Fresh water used in treatment (bbls): | 196266 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 7786485 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8814 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/26/2023 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 710 | | BBLS_OIL | 595 | | BTU_GAS | 1409 | | CALC_BBLS_H2O | 710 | | CALC_BBLS_OIL | 595 | | CALC_GOR | 2353 | | CALC_MCF_GAS | 1400 | | CASING_PRESS | 1256 | | GRAVITY_OIL | 44 | | MCF_GAS | 1400 | | TUBING_PRESS | 1330 |
| | Perforation Data: | | Interval Top: | 9184 ft. | # Of Holes: | 1272 | | Interval Bottom: | 21758 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 23014 |
| Total Gas Produced (MCF) | 160895 |
| GOR | 6991 |
| GOR Determination | BOE |
| Average BOE per Day | 138.709 |
| Average MCFE per Day | 804.505 |
| Federal Financial Assurance | i | |
|
|
