Wellbore #00 Wellbore Classification: OW Status: PR - 3/29/2023 Measured TD: 21828 ft. Vertical TD: 7965 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/29/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 4/10/2025 | | Proposed Top PZ Location: | Sec:22 Twp: 1S 67W | Footage: 2566 FSL 1580 FWL | | Bottom Hole Location: | Sec:34 Twp: 1S 67W | Footage: 476 FSL 2438 FEL | | Proposed Depth/Form: | 21891 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CARL , Formation: CARLILE , Order: 407-3725 , Unit Acreage: 1600, Drill Unit: 27&34:ALL SEC22:S2 | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 407-3725 , Unit Acreage: 1600, Drill Unit: 27&34:ALL SEC22:S2 | | Formation And Spacing: | Code: FTHYS , Formation: FORT HAYS , Order: 407-3725 , Unit Acreage: 1600, Drill Unit: 27&34:ALL SEC22:S2 | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-3725 , Unit Acreage: 1600, Drill Unit: 27&34:ALL SEC22:S2 | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2021 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 853, Top: 0 ft., Bottom: 2021 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 21891 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 3209, Top: , Bottom: 21891 ft. |
| | |
| Wellbore Completed | | Completion Date: | 7/6/2022 | | Spud Date: | 5/30/2022 | Spud Date Is: | ACTUAL | | Measured TD: | 21828 ft. | Measured PB depth: | 21806 ft. | | True Vertical TD: | 7965 ft. | True Vertical PB depth: | 7965 ft. | | Top PZ Location: | Sec:22 Twp: 1S 67W | Footage: 2566 FSL 1580 FWL | | Bottom Hole Location: | Sec:34 Twp: 1S 67W | Footage: 476 FSL 2438 FEL | | Log Types: | CBL, MWD (Composite log in 05-001-10516) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2081 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 944, Top: 0 ft., Bottom: 2081 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 21820 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2425, Top: 1230 ft., Bottom: 21820 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4927 ft. | | | | | SUSSEX | 5321 ft. | | | | | SHANNON | 6711 ft. | | | | | SHARON SPRINGS | 8107 ft. | | | | | NIOBRARA | 8282 ft. | | | | | FORT HAYS | 8963 ft. | | | | | CODELL | 9041 ft. | | | | | CARLILE | 15107 ft. | | | |
Formation CARL Formation Classification: OW Status: CM - 8/28/2024 Interval Top: 15107 ft. Interval Bottom: 15596 ft.| Completed Information for Formation CARLILE | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | CARLILE | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 8/28/2024 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 15,107' – 15,596’ | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CARL. |
| | Perforation Data: | | Interval Top: | 15107 ft. | # Of Holes: | 1272 | | Interval Bottom: | 15596 ft. | Hole Size: | 0.42 in. |
|
Formation NBRR Formation Classification: OW Status: CM - 8/28/2024 Interval Top: 10694 ft. Interval Bottom: 11157 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 8/28/2024 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 10,694' – 11,157' | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation NBRR. |
| | Perforation Data: | | Interval Top: | 10694 ft. | # Of Holes: | 1272 | | Interval Bottom: | 11157 ft. | Hole Size: | 0.42 in. |
|
Formation FTHYS Formation Classification: OW Status: CM - 8/28/2024 Interval Top: 10119 ft. Interval Bottom: 16460 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 8/28/2024 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 10,119' – 10,694', 12,038' – 12,367', 16,265' – 16,460' | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 10119 ft. | # Of Holes: | 1272 | | Interval Bottom: | 16460 ft. | Hole Size: | 0.42 in. |
|
Formation CODL Formation Classification: OW Status: CM - 8/28/2024 Interval Top: 9244 ft. Interval Bottom: 21820 ft.| Completed Information for Formation CODELL | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 8/28/2024 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 9,244’- - 10,119', 11,157' – 12,038', 12,367' – 15,107', 15,596' – 16,265', 16460' – 21,820' | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 9244 ft. | # Of Holes: | 1272 | | Interval Bottom: | 21820 ft. | Hole Size: | 0.42 in. |
|
Formation NFCC Formation Classification: OW Status: PR - 3/29/2023 Interval Top: 9244 ft. Interval Bottom: 21820 ft.| Completed Information for Formation NIOBRARA-FORT HAYS-CODELL-CARLILE | | 1st Production Date: | 3/21/2023 | Choke Size: | | | Formation Name: | NIOBRARA-FORT HAYS-CODELL-CARLILE | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 12/28/2022 | Treatment End Date: | 1/12/2023 | | Treatment Summary: | 36 Stage Plug and Perf
Total Fluid: 233,212 bbls
Gel Fluid: 163,554 bbls
Slickwater Fluid: 68,997 bbls
15% HCl Acid: 661 bbls
Total Proppant: 15,387,487 lbs
Silica Proppant: 15,387,487 lbs
Method for determining flowback: Measuring flowback tank volumes. | | Total fluid used in treatment (bbls): | 233212 | Max pressure during treatment (psi): | 4283 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 36 | | Total acid used in treatment (bbls): | 661 | Min frac gradient (psi/ft): | 0.88 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 18720 | | Fresh water used in treatment (bbls): | 232551 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 15387487 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8721 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/29/2023 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 1011 | | BBLS_OIL | 514 | | BTU_GAS | 1409 | | CALC_BBLS_H2O | 1011 | | CALC_BBLS_OIL | 514 | | CALC_GOR | 1060 | | CALC_MCF_GAS | 545 | | CASING_PRESS | 2368 | | GRAVITY_OIL | 44 | | MCF_GAS | 545 | | TUBING_PRESS | 1736 |
| | Perforation Data: | | Interval Top: | 9244 ft. | # Of Holes: | 1272 | | Interval Bottom: | 21820 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 51063 |
| Total Gas Produced (MCF) | 237655 |
| GOR | 4654 |
| GOR Determination | BOE |
| Average BOE per Day | 252.192 |
| Average MCFE per Day | 1462.713 |
| Federal Financial Assurance | i | |
|
|
