Wellbore #00 Wellbore Classification: OW Status: PR - 8/1/2024 Measured TD: 18077 ft. Vertical TD: 7837 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 8/1/2024 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 3/31/2021 | | Proposed Top PZ Location: | Sec:35 Twp: 3S 65W | Footage: 2241 FSL 460 FEL | | Bottom Hole Location: | Sec:34 Twp: 3S 65W | Footage: 2252 FSL 460 FWL | | Proposed Depth/Form: | 18111 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-1170 , Unit Acreage: 1280, Drill Unit: Sec. 34,35: All | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 99 ft., Weight: 42 , Citings Type: PLANNED | | Cement: | Sacks: 86, Top: 0 ft., Bottom: 99 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2056 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 1110, Top: 0 ft., Bottom: 2056 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18111 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2667, Top: , Bottom: 18111 ft. |
| | |
| Wellbore Completed | | Completion Date: | 6/12/2021 | | Spud Date: | 3/11/2021 | Spud Date Is: | ACTUAL | | Measured TD: | 18077 ft. | Measured PB depth: | 18048 ft. | | True Vertical TD: | 7837 ft. | True Vertical PB depth: | 7836 ft. | | Top PZ Location: | Sec:35 Twp: 3S 65W | Footage: 2218 FSL 486 FEL | | Bottom Hole Location: | Sec:34 Twp: 3S 65W | Footage: 2260 FSL 465 FWL | | Log Types: | Mud, MWD/LWD, CBL, Casing evaluation tool, (Resistivity on 001-09805). | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 124 ft., Weight: 52.78 , Citings Type: ACTUAL | | Cement: | Sacks: 0, Top: 0 ft., Bottom: 124 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2112 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 1039, Top: 0 ft., Bottom: 2112 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18062 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2654, Top: 2054 ft., Bottom: 18062 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | DENVER | 24 ft. | 1232 ft. | N | N | | LARAMIE | 1232 ft. | 1590 ft. | N | N | | FOX HILLS | 1590 ft. | 1861 ft. | N | N | | PIERRE | 1861 ft. | 7850 ft. | N | N | | NIOBRARA | 7850 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 8/1/2024 Interval Top: 8432 ft. Interval Bottom: 18038 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 11/7/2021 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 9/2/2021 | Treatment End Date: | 9/26/2021 | | Treatment Summary: | 53 stage frac;
617507 total bbls fluid pumped: 615395 bbls water, 199 bbls additives (FRP-22G, Bardac 2250M, T-Chlor 12.5, ACI-97, ASF-67), and 1913 bbl HCl acid;
199293 total lbs proppant pumped: 2747 Ibs DFR-1X, 47256 Ibs DFR-2S, and 149290 lbs silica quartz proppant. | | Total fluid used in treatment (bbls): | 617507 | Max pressure during treatment (psi): | 8788 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 53 | | Total acid used in treatment (bbls): | 1913 | Min frac gradient (psi/ft): | 0.88 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 646 | | Fresh water used in treatment (bbls): | 615395 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 199293 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8060 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 11/17/2021 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 820 | | BBLS_OIL | 73 | | BTU_GAS | 1485 | | CALC_BBLS_H2O | 820 | | CALC_BBLS_OIL | 73 | | CALC_GOR | 1096 | | CALC_MCF_GAS | 80 | | GRAVITY_OIL | 38 | | MCF_GAS | 80 | | TUBING_PRESS | 2344 |
| | Perforation Data: | | Interval Top: | 8432 ft. | # Of Holes: | 2305 | | Interval Bottom: | 18038 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 19998 |
| Total Gas Produced (MCF) | 106353 |
| GOR | 5318 |
| GOR Determination | BOE |
| Average BOE per Day | 105.158 |
| Average MCFE per Day | 609.911 |
| Federal Financial Assurance | i | |
|
|
