Wellbore #00 Wellbore Classification: OW Status: PR - 8/1/2024 Measured TD: 18469 ft. Vertical TD: 7827 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 8/1/2024 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 3/31/2021 | | Proposed Top PZ Location: | Sec:35 Twp: 3S 65W | Footage: 1081 FSL 460 FEL | | Bottom Hole Location: | Sec:34 Twp: 3S 65W | Footage: 1092 FSL 460 FWL | | Proposed Depth/Form: | 18486 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-1170 , Unit Acreage: 1280, Drill Unit: Sec. 34,35: All | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 99 ft., Weight: 42 , Citings Type: PLANNED | | Cement: | Sacks: 86, Top: 0 ft., Bottom: 99 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2096 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 1131, Top: 0 ft., Bottom: 2096 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18486 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2730, Top: , Bottom: 18486 ft. |
| | |
| Wellbore Completed | | Completion Date: | 5/31/2021 | | Spud Date: | 3/13/2021 | Spud Date Is: | ACTUAL | | Measured TD: | 18469 ft. | Measured PB depth: | 18446 ft. | | True Vertical TD: | 7827 ft. | True Vertical PB depth: | 7827 ft. | | Top PZ Location: | Sec:35 Twp: 3S 65W | Footage: 1045 FSL 487 FEL | | Bottom Hole Location: | Sec:34 Twp: 3S 65W | Footage: 1082 FSL 465 FWL | | Log Types: | Mud, MWD/LWD, CBL, Casing evaluation tool, (Resistivity on 001-09805). | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 124 ft., Weight: 52.78 , Citings Type: ACTUAL | | Cement: | Sacks: , Top: 0 ft., Bottom: 124 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2149 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 1059, Top: 0 ft., Bottom: 2149 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18461 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2731, Top: 2090 ft., Bottom: 18461 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | DENVER | 24 ft. | 1232 ft. | N | N | | LARAMIE | 1232 ft. | 1590 ft. | N | N | | FOX HILLS | 1590 ft. | 1861 ft. | N | N | | PIERRE | 1861 ft. | 8168 ft. | N | N | | NIOBRARA | 8168 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 8/1/2024 Interval Top: 8825 ft. Interval Bottom: 18437 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 10/31/2021 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 9/3/2021 | Treatment End Date: | 10/13/2021 | | Treatment Summary: | 55 stage frac;
647351 total bbls fluid pumped: 645113 bbls fresh water, 218 bbls additives (FRP-22G, Bardac 2250M, Dixichlor Max, T-Chlor 12.5, ACI-97, ASF-67), and 2020 bbls HCl acid;
207346 total lbs proppant pumped: 3423 Ibs DFR-1X, 49738 Ibs DFR-2S, and 154185 lbs silica quartz proppant. | | Total fluid used in treatment (bbls): | 647351 | Max pressure during treatment (psi): | 9031 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 55 | | Total acid used in treatment (bbls): | 2020 | Min frac gradient (psi/ft): | 0.88 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 18783 | | Fresh water used in treatment (bbls): | 645113 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 207346 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8399 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 11/17/2021 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 973 | | BBLS_OIL | 169 | | BTU_GAS | 1472 | | CALC_BBLS_H2O | 973 | | CALC_BBLS_OIL | 169 | | CALC_GOR | 1107 | | CALC_MCF_GAS | 187 | | CASING_PRESS | 57 | | GRAVITY_OIL | 38 | | MCF_GAS | 187 | | TUBING_PRESS | 2177 |
| | Perforation Data: | | Interval Top: | 8825 ft. | # Of Holes: | 2388 | | Interval Bottom: | 18437 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 29366 |
| Total Gas Produced (MCF) | 106248 |
| GOR | 3618 |
| GOR Determination | BOE |
| Average BOE per Day | 130.665 |
| Average MCFE per Day | 757.868 |
| Federal Financial Assurance | i | |
|
|
