COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITGIS Map GISOld GIS Map Old GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-001-10340		Well Classification: OW Status: PR - 6/1/2020
Well Name/No:Brant LE #08-159HC
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PDC ENERGY INC - 69175
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date6/1/2020
FacilityID:460116LocationID:460107
County:ADAMS #001Location:SENE 11 1S67W 6
Field:WATTENBERG - #90750Elevation:4973 ft.
Basin:DENVER (DJ) BASIN
Planned Location:2202FNL  377 FELLat/Long: 39.980764 / -104.848088Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 39.980764 / -104.848088Lat/Long Source: Field Measured

FracFocus
Disclosure: Sidetrack #01
Start Date: 3/12/2020
End Date: 4/7/2020
Reported: 4/20/2020
Days to report: 13
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: AB - 12/4/2019             Measured TD: 23212 ft.    Vertical TD: 7625 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        AB - 12/4/2019
Wellbore PermitHORIZONTAL
Permit #:Expiration Date:12/19/2020
Proposed Top PZ Location:Sec:12 Twp: 1S 67W Footage: 1975 FNL  460 FWL
Bottom Hole Location:Sec:08 Twp: 1S 66W Footage: 1975 FNL  370 FEL
Proposed Depth/Form:23101 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: 407-2246 , Unit Acreage: 1923, Drill Unit: Sec 12, 7 & 8: ALL
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1700 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 717, Top: 0 ft., Bottom: 1700 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23101 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 3144, Top: , Bottom: 23101 ft.
Wellbore Completed
Completion Date:12/6/2019
Spud Date:12/6/2019Spud Date Is:ACTUAL
Measured TD:23212 ft.Measured PB depth:23212 ft.
True Vertical TD:7625 ft.True Vertical PB depth:7625 ft.
Bottom Hole Location:Sec:8 Twp: 1S 66WFootage: 1959 FNL  384 FEL
Log Types:Mud Log, MWD/LWD, (Composite in 001-10345)
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1779 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 800, Top: 0 ft., Bottom: 1779 ft., Determination Method: VISU
Casing:String Type: OPEN HOLE, Hole Size: 8.5 in., Size: , Top: 1779 ft., Depth: 23212 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: , Top: , Bottom: , Determination Method:
FormationInterval TopLog BottomCoredDSTs
PARKMAN4399 ft.4579 ft.NN
SUSSEX4797 ft.4943 ft.NN
SHANNON5355 ft.5519 ft.NN
SHARON SPRINGS7269 ft.NN
NIOBRARA7291 ft.NN
FORT HAYS7879 ft.NN
CODELL7958 ft.NN
CARLILE17123 ft.NN
  No formation data to display.

Sidetrack #01             Wellbore Classification: OW             Status: PR - 6/1/2020             Measured TD: 23337 ft.    Vertical TD: 7615 ft.

 Wellbore Data for Sidetrack #01Wellbore Classification: OW        PR - 6/1/2020
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:1/13/2022
Proposed Top PZ Location:Sec:12 Twp: 1S 67W Footage: 1977 FNL  520 FWL
Bottom Hole Location:Sec:8 Twp: 1S 66W Footage: 2015 FNL  258 FEL
Proposed Depth/Form:23306 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CARL , Formation: CARLILE , Order: 407-3712 , Unit Acreage: 1923, Drill Unit: Sec 12,7 & 8 ALL
Formation And Spacing:Code: CODL , Formation: CODELL , Order: 407-3712 , Unit Acreage: 1923, Drill Unit: Sec 12,7 & 8 ALL
Formation And Spacing:Code: FTHYS , Formation: FORT HAYS , Order: 407-3712 , Unit Acreage: 1923, Drill Unit: Sec 12,7 & 8 ALL
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: 407-3712 , Unit Acreage: 1923, Drill Unit: Sec 12,7 & 8 ALL
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1779 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 800, Top: 0 ft., Bottom: 1779 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23306 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 3030, Top: , Bottom: 23306 ft.
Wellbore Completed
Completion Date:1/17/2020
Spud Date:12/6/2019Spud Date Is:ACTUAL
Measured TD:23337 ft.Measured PB depth:23326 ft.
True Vertical TD:7615 ft.True Vertical PB depth:7616 ft.
Top PZ Location:Sec:12 Twp: 1S 67WFootage: 1977 FNL  520 FWL
Bottom Hole Location:Sec:8 Twp: 1S 66WFootage: 2015 FNL  258 FEL
Log Types:Mud Log, MWD/LWD, CBL (Composite in 05-001-10345)
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1779 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 800, Top: 0 ft., Bottom: 1779 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23337 ft., Weight: 20 , Citings Type: ACTUAL
Cement:Sacks: 3325, Top: 3904 ft., Bottom: 23337 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
CODELL19340 ft.NN
FORT HAYS20935 ft.NN

Formation CARL                     Formation Classification:  OW                     Status:  CM - 10/24/2024                Interval Top: 17123 ft.    Interval Bottom: 17861 ft.

 Completed Information for Formation CARLILE
1st Production Date:5/29/2020Choke Size:
Formation Name:CARLILECommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:10/24/2024Treatment End Date:N/A
Treatment Summary:Carlile Perf Interval: 17123' - 17861'
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CARL.
Perforation Data:
Interval Top:17123 ft.# Of Holes:2160
Interval Bottom:17861 ft.Hole Size:0.38 in.

Formation FTHYS                   Formation Classification:  OW                   Status:  CM - 10/24/2024                Interval Top: 13482 ft.    Interval Bottom: 22063 ft.

 Completed Information for Formation FORT HAYS
1st Production Date:5/29/2020Choke Size:
Formation Name:FORT HAYSCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:10/24/2024Treatment End Date:N/A
Treatment Summary:FT. Hays Perf Interval: 13482' - 13818'; 16389' - 17122'; 20935' - 21731'; 21830' - 22063'
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation FTHYS.
Perforation Data:
Interval Top:13482 ft.# Of Holes:2160
Interval Bottom:22063 ft.Hole Size:0.38 in.

Formation NBRR                     Formation Classification:  OW                     Status:  CM - 10/24/2024                Interval Top: 13047 ft.    Interval Bottom: 13481 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:5/29/2020Choke Size:
Formation Name:NIOBRARACommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:10/24/2024Treatment End Date:N/A
Treatment Summary:Niobrara Perf Interval: 13047' - 13481'
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation NBRR.
Perforation Data:
Interval Top:13047 ft.# Of Holes:2160
Interval Bottom:13481 ft.Hole Size:0.38 in.

Formation CODL                     Formation Classification:  OW                     Status:  CM - 10/24/2024                Interval Top: 8170 ft.    Interval Bottom: 23063 ft.

 Completed Information for Formation CODELL
1st Production Date:5/29/2020Choke Size:
Formation Name:CODELLCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:10/24/2024Treatment End Date:N/A
Treatment Summary:Codell Perf Interval: 8170' - 13046'; 13819' - 16388'; 17862' - 20934'; 21732' - 21829'; 22064' - 23063'
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CODL.
Perforation Data:
Interval Top:8170 ft.# Of Holes:2160
Interval Bottom:23063 ft.Hole Size:0.38 in.

Formation NFCC                     Formation Classification:  OW                     Status:  PR - 6/1/2020                  Interval Top: 8170 ft.    Interval Bottom: 23063 ft.

 Completed Information for Formation NIOBRARA-FORT HAYS-CODELL-CARLILE
1st Production Date:5/29/2020Choke Size:
Formation Name:NIOBRARA-FORT HAYS-CODELL-CARLILECommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:FRACTURE STIMULATION
Treatment Date:3/12/2020Treatment End Date:4/7/2020
Treatment Summary:107 bbls 15% HCL Acid; 747,968 # 100 Mesh Sand; 13,519,697 # 20/40 Sand; 277,765 bbls gelled fluid; Flowback determined from well test separator.
Total fluid used in treatment (bbls):277872Max pressure during treatment (psi):5144
Total gas used in treatment (mcf):Fluid density (lbs/gal):8.33
Type Of gas:Number Of staged intervals:72
Total acid used in treatment (bbls):107Min frac gradient (psi/ft):0.89
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):61780
Fresh water used in treatment (bbls):277765Disposition method For flowback:DISPOSAL
Total proppant used (lbs):14267665Green completions techniques utilized:Yes
Reason green techniques Not utilized:
Tubing Size:2.375 in.Tubing Setting Depth:7514 ft.
Tubing Packer Depth:7505 ft.Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:6/1/2020Test Method:
Hours Tested:24Gas Type:WET
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 355
BBLS_OIL 504
BTU_GAS 1500
CALC_BBLS_H2O 355
CALC_BBLS_OIL 504
CALC_GOR 966
CALC_MCF_GAS 487
GRAVITY_OIL 41
MCF_GAS 487
TUBING_PRESS 1717
Perforation Data:
Interval Top:8170 ft.# Of Holes:2160
Interval Bottom:23063 ft.Hole Size:0.38 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
January 2025 - December 2025i
Total Oil Produced (Barrels)10599
Total Gas Produced (MCF)56249
GOR5307
GOR DeterminationBOE
Average BOE per Day56.162
Average MCFE per Day325.728

 Federal Financial Assurance  i

 Tribal Well  i No
