Wellbore #00 Wellbore Classification: OW Status: PR - 6/1/2020 Measured TD: 23233 ft. Vertical TD: 7501 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 6/1/2020 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 12/19/2020 | | Proposed Top PZ Location: | Sec:12 Twp: 1S 67W | Footage: 1605 FNL 460 FWL | | Bottom Hole Location: | Sec:08 Twp: 1S 66W | Footage: 1605 FNL 370 FEL | | Proposed Depth/Form: | 23027 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-2246 , Unit Acreage: 1923, Drill Unit: Sec 12, 7 & 8: All | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1700 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 717, Top: 0 ft., Bottom: 1700 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23027 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 3131, Top: , Bottom: 23027 ft. |
| | |
| Wellbore Completed | | Completion Date: | 12/18/2019 | | Spud Date: | 12/4/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 23233 ft. | Measured PB depth: | 23222 ft. | | True Vertical TD: | 7501 ft. | True Vertical PB depth: | 7501 ft. | | Top PZ Location: | Sec:12 Twp: 1S 67W | Footage: 1597 FNL 594 FWL | | Bottom Hole Location: | Sec:8 Twp: 1S 66W | Footage: 1606 FNL 262 FEL | | Log Types: | Mud Log, MWD/LWD, CBL (Composite in 05-001-10345) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1766 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 800, Top: 0 ft., Bottom: 1766 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23233 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 3320, Top: 2260 ft., Bottom: 23233 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4384 ft. | 4566 ft. | N | N | | SUSSEX | 4794 ft. | 4943 ft. | N | N | | SHANNON | 5358 ft. | 5524 ft. | N | N | | SHARON SPRINGS | 7331 ft. | | N | N | | NIOBRARA | 7352 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 6/1/2020 Interval Top: 8151 ft. Interval Bottom: 22973 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 5/27/2020 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 3/12/2020 | Treatment End Date: | 4/13/2020 | | Treatment Summary: | 4226 bbls 15% HCL Acid; 1,140,929# 100 Mesh Sand; 13,059,061# 20/40 Sand; 350,567 bbls Gelled Fluid; Flowback determined from well test separator | | Total fluid used in treatment (bbls): | 354793 | Max pressure during treatment (psi): | 4968 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 95 | | Total acid used in treatment (bbls): | 4226 | Min frac gradient (psi/ft): | 0.92 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 43920 | | Fresh water used in treatment (bbls): | 350567 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 14199990 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7326 ft. | | Tubing Packer Depth: | 7317 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 6/1/2020 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 520 | | BBLS_OIL | 372 | | BTU_GAS | 1500 | | CALC_BBLS_H2O | 520 | | CALC_BBLS_OIL | 372 | | CALC_GOR | 980 | | CALC_MCF_GAS | 365 | | GRAVITY_OIL | 41 | | MCF_GAS | 365 | | TUBING_PRESS | 1369 |
| | Perforation Data: | | Interval Top: | 8151 ft. | # Of Holes: | 2470 | | Interval Bottom: | 22973 ft. | Hole Size: | 0.18 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 8158 |
| Total Gas Produced (MCF) | 81890 |
| GOR | 10037 |
| GOR Determination | BOE |
| Average BOE per Day | 61.156 |
| Average MCFE per Day | 354.717 |
| Federal Financial Assurance | i | |
|
|
