Wellbore #00 Wellbore Classification: OW Status: PR - 5/31/2020 Measured TD: 23174 ft. Vertical TD: 7475 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 5/31/2020 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 12/19/2020 | | Proposed Top PZ Location: | Sec:12 Twp: 1S 67W | Footage: 2352 FNL 594 FWL | | Bottom Hole Location: | Sec:8 Twp: 1S 66W | Footage: 2367 FNL 244 FEL | | Proposed Depth/Form: | 22673 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-2246 , Unit Acreage: 1923, Drill Unit: Sec 12, 7 & 8: ALL | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1700 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 717, Top: 0 ft., Bottom: 1700 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 22673 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 3073, Top: , Bottom: 22673 ft. |
| | |
| Wellbore Completed | | Completion Date: | 2/12/2020 | | Spud Date: | 12/7/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 23174 ft. | Measured PB depth: | 23164 ft. | | True Vertical TD: | 7475 ft. | True Vertical PB depth: | 7475 ft. | | Top PZ Location: | Sec:12 Twp: 1S 67W | Footage: 2352 FNL 594 FWL | | Bottom Hole Location: | Sec:8 Twp: 1S 66W | Footage: 2367 FNL 244 FEL | | Log Types: | Mud Log, MWD/LWD, CBL (Composite in 05-001-10345) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1797 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 800, Top: 0 ft., Bottom: 1797 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23174 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 3303, Top: 1920 ft., Bottom: 23174 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4391 ft. | 4574 ft. | N | N | | SUSSEX | 4796 ft. | 4934 ft. | N | N | | SHANNON | 5350 ft. | 5522 ft. | N | N | | SHARON SPRINGS | 7282 ft. | | N | N | | NIOBRARA | 7308 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 5/31/2020 Interval Top: 8071 ft. Interval Bottom: 22880 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 5/29/2020 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 3/12/2020 | Treatment End Date: | 4/11/2020 | | Treatment Summary: | 3619 bbls 15% HCL Acid; 1,135,194 # 100 Mesh Sand; 13,121,961 # 20/40 Sand; 349,450 bbls Gelled Fluid; Flowback determined from well test separator | | Total fluid used in treatment (bbls): | 353069 | Max pressure during treatment (psi): | 4478 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 95 | | Total acid used in treatment (bbls): | 3619 | Min frac gradient (psi/ft): | 0.87 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 45124 | | Fresh water used in treatment (bbls): | 349450 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 14257155 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7363 ft. | | Tubing Packer Depth: | 7354 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 5/31/2020 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 443 | | BBLS_OIL | 438 | | BTU_GAS | 1500 | | CALC_BBLS_H2O | 443 | | CALC_BBLS_OIL | 438 | | CALC_GOR | 979 | | CALC_MCF_GAS | 429 | | GRAVITY_OIL | 41 | | MCF_GAS | 429 | | TUBING_PRESS | 1408 |
| | Perforation Data: | | Interval Top: | 8071 ft. | # Of Holes: | 2470 | | Interval Bottom: | 22880 ft. | Hole Size: | 0.38 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 14259 |
| Total Gas Produced (MCF) | 16651 |
| GOR | 1167 |
| GOR Determination | BOE |
| Average BOE per Day | 46.782 |
| Average MCFE per Day | 271.303 |
| Federal Financial Assurance | i | |
|
|
