Wellbore #00 Wellbore Classification: OW Status: PR - 11/23/2023 Measured TD: 23292 ft. Vertical TD: 7611 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 11/23/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 9/19/2025 | | Proposed Top PZ Location: | Sec:12 Twp: 1S 67W | Footage: 1550 FSL 460 FWL | | Bottom Hole Location: | Sec:8 Twp: 1S 66W | Footage: 1550 FSL 460 FEL | | Proposed Depth/Form: | 23322 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CARL , Formation: CARLILE , Order: 407-3712 , Unit Acreage: 1923, Drill Unit: S12-1S-67W: ALL; S7- | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 407-3712 , Unit Acreage: 1923, Drill Unit: S12-1S-67W: ALL; S7- | | Formation And Spacing: | Code: FTHYS , Formation: FORT HAYS , Order: 407-3712 , Unit Acreage: 1923, Drill Unit: S12-1S-67W: ALL; S7- | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-3712 , Unit Acreage: 1923, Drill Unit: S12-1S-67W: ALL; S7- | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1600 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 920, Top: 0 ft., Bottom: 1600 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23322 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2035, Top: , Bottom: 23322 ft. |
| | |
| Wellbore Completed | | Completion Date: | 3/28/2023 | | Spud Date: | 12/8/2022 | Spud Date Is: | ACTUAL | | Measured TD: | 23292 ft. | Measured PB depth: | 23268 ft. | | True Vertical TD: | 7611 ft. | True Vertical PB depth: | 7610 ft. | | Top PZ Location: | Sec:12 Twp: 1S 67W | Footage: 1555 FSL 512 FWL | | Bottom Hole Location: | Sec:8 Twp: 1S 66W | Footage: 1557 FSL 466 FEL | | Log Types: | | | Log Types: | CBL, MWD (DIL in 05-001-10345) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2112 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 960, Top: 0 ft., Bottom: 2112 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23282 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 4309, Top: 0 ft., Bottom: 23282 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4524 ft. | | | | | SUSSEX | 4818 ft. | | | | | SHANNON | 5312 ft. | | | | | SHARON SPRINGS | 7380 ft. | | | | | NIOBRARA | 7411 ft. | | | | | FORT HAYS | 8055 ft. | | | | | CODELL | 8161 ft. | | | |
Formation NBRR Formation Classification: OW Status: CM - 1/30/2026 Interval Top: 9020 ft. Interval Bottom: 13462 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 1/30/2026 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 9,020’-9,420’, 13,054’-13,462’ | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation NBRR. |
| | Perforation Data: | | Interval Top: | 9020 ft. | # Of Holes: | 1488 | | Interval Bottom: | 13462 ft. | Hole Size: | 0.42 in. |
|
Formation FTHYS Formation Classification: OW Status: CM - 1/30/2026 Interval Top: 8656 ft. Interval Bottom: 15505 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 1/30/2026 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 8,656’-9,020’, 9,420’-9,878’, 10,808’-11,109’, 12,600’-12,828’, 13,462’-14,270’, 15,185’-15,505’ | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 8656 ft. | # Of Holes: | 1488 | | Interval Bottom: | 15505 ft. | Hole Size: | 0.42 in. |
|
Formation CODL Formation Classification: OW Status: CM - 1/30/2026 Interval Top: 8320 ft. Interval Bottom: 23282 ft.| Completed Information for Formation CODELL | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 1/30/2026 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 8,320’-8,656’, 9,878’-10,808’, 11,109’-12,600’, 12,828’-13,054’, 14,270’-15,185’, 15,505’-23,282’ | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 8320 ft. | # Of Holes: | 1488 | | Interval Bottom: | 23282 ft. | Hole Size: | 0.42 in. |
|
Formation NBFHC Formation Classification: OW Status: PR - 11/23/2023 Interval Top: 8320 ft. Interval Bottom: 23282 ft.| Completed Information for Formation NIOBRARA-FT HAYS-CODELL | | 1st Production Date: | 11/14/2023 | Choke Size: | | | Formation Name: | NIOBRARA-FT HAYS-CODELL | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 8/28/2023 | Treatment End Date: | 9/14/2023 | | Treatment Summary: | 43 Stage Plug and Perf
Total Fluid: 296,801 bbls
Gel Fluid: 211,316 bbls
Slickwater Fluid: 84,986 bbls
15% HCl Acid: 499 bbls
Total Proppant: 18,140,945 lbs
Silica Proppant: 18,140,945 lbs
Method for determining flowback: Measuring flowback tank volumes. | | Total fluid used in treatment (bbls): | 296801 | Max pressure during treatment (psi): | 4211 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 43 | | Total acid used in treatment (bbls): | 499 | Min frac gradient (psi/ft): | 0.87 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 23577 | | Fresh water used in treatment (bbls): | 296302 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 18140945 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7868 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 11/23/2023 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 251 | | BBLS_OIL | 197 | | BTU_GAS | 1333 | | CALC_BBLS_H2O | 251 | | CALC_BBLS_OIL | 197 | | CALC_GOR | 1548 | | CALC_MCF_GAS | 305 | | CASING_PRESS | 2675 | | GRAVITY_OIL | 60 | | MCF_GAS | 305 | | TUBING_PRESS | 2098 |
| | Perforation Data: | | Interval Top: | 8320 ft. | # Of Holes: | 1488 | | Interval Bottom: | 23282 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 46497 |
| Total Gas Produced (MCF) | 392743 |
| GOR | 8446 |
| GOR Determination | BOE |
| Average BOE per Day | 311.393 |
| Average MCFE per Day | 1806.096 |
