Wellbore #00 Wellbore Classification: OW Status: PR - 12/21/2021 Measured TD: 12120 ft. Vertical TD: 7447 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 12/21/2021 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 10/16/2020 | | Proposed Top PZ Location: | Sec:2 Twp: 1S 66W | Footage: 1765 FSL 460 FEL | | Bottom Hole Location: | Sec:2 Twp: 1S 66W | Footage: 1765 FSL 460 FWL | | Proposed Depth/Form: | 12248 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-2163 , Unit Acreage: 640, Drill Unit: Sec 2 ALL | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 42 , Citings Type: PLANNED | | Cement: | Sacks: 400, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 576, Top: 0 ft., Bottom: 1500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 12248 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 1463, Top: , Bottom: 12248 ft. |
| | |
| Wellbore Completed | | Completion Date: | 8/23/2021 | | Spud Date: | 9/19/2020 | Spud Date Is: | ACTUAL | | Measured TD: | 12120 ft. | Measured PB depth: | 12093 ft. | | True Vertical TD: | 7447 ft. | True Vertical PB depth: | 7447 ft. | | Top PZ Location: | Sec:2 Twp: 1S 66W | Footage: 1768 FSL 478 FEL | | Bottom Hole Location: | Sec:2 Twp: 1S 66W | Footage: 1762 FSL 432 FWL | | Log Types: | | | Log Types: | MWD/LWD, CBL, MUD, RES/GR in API 05-001-10215 | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 400, Top: 0 ft., Bottom: 80 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1532 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 435, Top: 0 ft., Bottom: 1532 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 12107 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 1590, Top: 1900 ft., Bottom: 12107 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | FOX HILLS | 948 ft. | 1201 ft. | N | N | | SUSSEX | 4835 ft. | 5570 ft. | N | N | | SHANNON | 5570 ft. | 7045 ft. | N | N | | SHARON SPRINGS | 7045 ft. | 7265 ft. | N | N | | NIOBRARA | 7265 ft. | 12120 ft. | N | N |
Formation NBRR Formation Classification: OW Status: PR - 12/21/2021 Interval Top: 7748 ft. Interval Bottom: 12027 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 12/22/2021 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 10/14/2021 | Treatment End Date: | 10/19/2021 | | Treatment Summary: | Frac Summary: 29 Stages, LibertyFR, 5,655,160 total lbs 40/70 White & 100 Mesh sand, 163,173 total bbls fluid, no HCl. Ave Rate 89 bpm, Ave PSI 6,755, Max PSI 8,525 | | Total fluid used in treatment (bbls): | 163173 | Max pressure during treatment (psi): | 8525 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 29 | | Total acid used in treatment (bbls): | 0 | Min frac gradient (psi/ft): | 1.01 | | Recycled water used in treatment (bbls): | 7313 | Total flowback volume recovered (bbls): | 14398 | | Fresh water used in treatment (bbls): | 155860 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 5655160 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7442 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 12/21/2021 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 337 | | BBLS_OIL | 289 | | BTU_GAS | 1405 | | CALC_BBLS_H2O | 337 | | CALC_BBLS_OIL | 289 | | CALC_GOR | 377 | | CALC_MCF_GAS | 109 | | CASING_PRESS | 1757 | | GRAVITY_OIL | 42 | | MCF_GAS | 109 | | TUBING_PRESS | 1193 |
| | Perforation Data: | | Interval Top: | 7748 ft. | # Of Holes: | 1044 | | Interval Bottom: | 12027 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 5548 |
| Total Gas Produced (MCF) | 66293 |
| GOR | 11948 |
| GOR Determination | BOE |
| Average BOE per Day | 46.469 |
| Average MCFE per Day | 269.522 |
| Federal Financial Assurance | i | |
|
|
