Wellbore #00 Wellbore Classification: OW Status: PR - 9/26/2021 Measured TD: 23680 ft. Vertical TD: 7937 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 9/26/2021 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 11/9/2022 | | Proposed Top PZ Location: | Sec:14 Twp: 1S 68W | Footage: 460 FNL 927 FEL | | Bottom Hole Location: | Sec:26 Twp: 1S 68W | Footage: 286 FSL 912 FEL | | Proposed Depth/Form: | 23506 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 407-1904 , Unit Acreage: 960, Drill Unit: Sec 14, 23 & 26:E2 | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-1904 , Unit Acreage: 960, Drill Unit: Sec. 14, 23, 26: E2 | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1700 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 717, Top: 0 ft., Bottom: 1700 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23506 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 3203, Top: , Bottom: 23506 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 7186 ft., Depth: 15730 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 2/5/2021 | | Spud Date: | 12/17/2020 | Spud Date Is: | ACTUAL | | Measured TD: | 23680 ft. | Measured PB depth: | 23675 ft. | | True Vertical TD: | 7937 ft. | True Vertical PB depth: | 7937 ft. | | Top PZ Location: | Sec:14 Twp: 1S 68W | Footage: 460 FNL 927 FEL | | Bottom Hole Location: | Sec:26 Twp: 1S 68W | Footage: 286 FSL 912 FEL | | Log Types: | Mud log, MWD/LWD, CBL (Composite in 001-09900) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2024 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 895, Top: 0 ft., Bottom: 2024 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 23680 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 3295, Top: 3730 ft., Bottom: 23680 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4490 ft. | 4646 ft. | N | N | | SUSSEX | 4817 ft. | 5007 ft. | N | N | | SHANNON | 5280 ft. | 5346 ft. | N | N | | SHARON SPRINGS | 7639 ft. | | N | N | | NIOBRARA | 7842 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 9/26/2021 Interval Top: 8641 ft. Interval Bottom: 23494 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 9/22/2021 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 5/30/2021 | Treatment End Date: | 8/30/2021 | | Treatment Summary: | 2226 bbls 15% HCL Acid & 1583 bbls 7.5%; 886,508 # 100 Mesh Sand; 10,163,530 # 20/40 Sand; 285,140 bbls Gelled Fluid; Flowback determind from well test separator | | Total fluid used in treatment (bbls): | 288949 | Max pressure during treatment (psi): | 4553 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 74 | | Total acid used in treatment (bbls): | 3809 | Min frac gradient (psi/ft): | 0.89 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 36936 | | Fresh water used in treatment (bbls): | 285140 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 11050038 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8198 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 9/26/2021 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 698 | | BBLS_OIL | 315 | | BTU_GAS | 1398 | | CALC_BBLS_H2O | 698 | | CALC_BBLS_OIL | 315 | | CALC_GOR | 1829 | | CALC_MCF_GAS | 576 | | CASING_PRESS | 2838 | | GRAVITY_OIL | 45 | | MCF_GAS | 576 | | TUBING_PRESS | 2015 |
| | Perforation Data: | | Interval Top: | 8641 ft. | # Of Holes: | 1486 | | Interval Bottom: | 23494 ft. | Hole Size: | 0.34 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 6486 |
| Total Gas Produced (MCF) | 131058 |
| GOR | 20206 |
| GOR Determination | MCFE |
| Average BOE per Day | 79.692 |
| Average MCFE per Day | 462.262 |
| Federal Financial Assurance | i | |
|
|
