Wellbore #00 Wellbore Classification: OW Status: AB - 4/14/2025 Measured TD: 18251 ft. Vertical TD: 7911 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW AB - 4/14/2025 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 11/9/2022 | | Proposed Top PZ Location: | Sec:11 Twp: 1S 68W | Footage: 460 FSL 1974 FEL | | Bottom Hole Location: | Sec:2 Twp: 1S 68W | Footage: 293 FNL 1983 FEL | | Proposed Depth/Form: | 18125 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CARL , Formation: CARLILE , Order: 407-3711 , Unit Acreage: 640, Drill Unit: Sec. 2, 11: E2 | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 407-3711 , Unit Acreage: 640, Drill Unit: Sec. 2, 11: E2 | | Formation And Spacing: | Code: FTHYS , Formation: FORT HAYS , Order: 407-3711 , Unit Acreage: 640, Drill Unit: Sec. 2, 11: E2 | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-3711 , Unit Acreage: 640, Drill Unit: Sec. 2, 11: E2 | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1700 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 717, Top: 0 ft., Bottom: 1700 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18125 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 2309, Top: , Bottom: 18125 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 7186 ft., Depth: 16417 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 2/8/2021 | | Spud Date: | 12/21/2020 | Spud Date Is: | ACTUAL | | Measured TD: | 18251 ft. | Measured PB depth: | 18246 ft. | | True Vertical TD: | 7911 ft. | True Vertical PB depth: | 7911 ft. | | Top PZ Location: | Sec:11 Twp: 1S 68W | Footage: 460 FSL 1974 FEL | | Bottom Hole Location: | Sec:2 Twp: 1S 68W | Footage: 293 FNL 1983 FEL | | Log Types: | Mud log, MWD/LWD, CBL,Composite | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2021 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 1000, Top: 0 ft., Bottom: 2021 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18251 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2425, Top: 2589 ft., Bottom: 18251 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4471 ft. | 4634 ft. | N | N | | SUSSEX | 4812 ft. | 5015 ft. | N | N | | SHANNON | 5322 ft. | 5369 ft. | N | N | | SHARON SPRINGS | 7697 ft. | | N | N | | NIOBRARA | 7920 ft. | | N | N | | FORT HAYS | 8594 ft. | | N | N | | CODELL | 8825 ft. | | N | N | | CARLILE | 13631 ft. | | N | N |
Formation CARL Formation Classification: OW Status: CM - 10/9/2024 Interval Top: 13631 ft. Interval Bottom: 14153 ft.| Completed Information for Formation CARLILE | | 1st Production Date: | 8/5/2021 | Choke Size: | | | Formation Name: | CARLILE | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CARL. |
| | Perforation Data: | | Interval Top: | 13631 ft. | # Of Holes: | 1128 | | Interval Bottom: | 14153 ft. | Hole Size: | 0.38 in. |
|
Formation CODL Formation Classification: OW Status: CM - 10/9/2024 Interval Top: 8825 ft. Interval Bottom: 18022 ft.| Completed Information for Formation CODELL | | 1st Production Date: | 8/5/2021 | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 10/9/2024 | Treatment End Date: | N/A | | Treatment Summary: | Codell perf intervals: 8825-12632; 14154-16262; 16904-18022
| | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 8825 ft. | # Of Holes: | 1128 | | Interval Bottom: | 18022 ft. | Hole Size: | 0.38 in. |
|
Formation CLCDFH Formation Classification: OW Status: AB - 4/14/2025 Interval Top: 8760 ft. Interval Bottom: 18022 ft.| Completed Information for Formation CARLILE-CODELL-FORT HAYS | | 1st Production Date: | 8/5/2021 | Choke Size: | | | Formation Name: | CARLILE-CODELL-FORT HAYS | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 5/28/2021 | Treatment End Date: | 6/13/2021 | | Treatment Summary: | 667 bbls 15% HCL Acid; 469,323# 100 Mesh Sand; 6,550,955# 20/40 Sand; 165,700 bbls gelled fluid; Flowback determined from well test separator. | | Total fluid used in treatment (bbls): | 166367 | Max pressure during treatment (psi): | 4377 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 47 | | Total acid used in treatment (bbls): | 667 | Min frac gradient (psi/ft): | 0.84 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 12179 | | Fresh water used in treatment (bbls): | 165700 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 7020278 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8366 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 8/7/2021 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 313 | | BBLS_OIL | 553 | | BTU_GAS | 1398 | | CALC_BBLS_H2O | 313 | | CALC_BBLS_OIL | 553 | | CALC_GOR | 2030 | | CALC_MCF_GAS | 1123 | | CASING_PRESS | 2309 | | GRAVITY_OIL | 45 | | MCF_GAS | 1123 | | TUBING_PRESS | 2045 |
| | Perforation Data: | | Interval Top: | 8760 ft. | # Of Holes: | 1128 | | Interval Bottom: | 18022 ft. | Hole Size: | 0.38 in. |
|
Formation FTHYS Formation Classification: OW Status: CM - 10/9/2024 Interval Top: 8760 ft. Interval Bottom: 16903 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | 8/5/2021 | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 10/9/2024 | Treatment End Date: | N/A | | Treatment Summary: | FTHYS perf intervals: 8760-8824; 12633-13630; 16263-16903
| | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 8760 ft. | # Of Holes: | 1128 | | Interval Bottom: | 16903 ft. | Hole Size: | 0.38 in. |
|
|
|
|
|
|
|
| Reported Plugged | Y | 04/14/2025 |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 1336 |
| Total Gas Produced (MCF) | 16272 |
| GOR | 12179 |
| GOR Determination | BOE |
| Average BOE per Day | 11.285 |
| Average MCFE per Day | 65.446 |
| Federal Financial Assurance | i | |
|
|
