COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITGIS Map GISOld GIS Map Old GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-001-09845		Well Classification: OW Status: PR - 9/1/2023
Well Name/No:Ward Riverdale #14-4-12HC
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PDC ENERGY INC - 69175
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date9/1/2023
FacilityID:441675LocationID:441677
County:ADAMS #001Location:NWSW 14 1S67W 6
Field:WATTENBERG - #90750Elevation:5114 ft.
Basin:DENVER (DJ) BASIN
Planned Location:1880FSL  335 FWLLat/Long: 39.962840 / -104.864230Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 39.962843 / -104.864229Lat/Long Source: Field Measured

FracFocus
Disclosure: Sidetrack #00
Start Date: 6/7/2015
End Date: 6/11/2015
Reported: 6/16/2015
Days to report: 5
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PR - 9/1/2023             Measured TD: 12820 ft.    Vertical TD: 7856 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PR - 9/1/2023
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:4/30/2017
Proposed Top PZ Location:Sec:14 Twp: 1S 67W Footage: 480 FSL  460 FWL
Bottom Hole Location:Sec:14 Twp: 1S 67W Footage: 480 FSL  460 FEL
Proposed Depth/Form:12816 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: 407-1038 , Unit Acreage: 640, Drill Unit: All
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1200 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 1005, Top: 0 ft., Bottom: 1200 ft.
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 5.5 in., Top: 0 ft., Depth: 12800 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 844, Top: 4400 ft., Bottom: 12800 ft.
Wellbore Completed
Completion Date:5/17/2015
Spud Date:5/8/2015Spud Date Is:ACTUAL
Measured TD:12820 ft.Measured PB depth:12755 ft.
True Vertical TD:7856 ft.True Vertical PB depth:7855 ft.
Top PZ Location:Sec:14 Twp: 1S 67WFootage: 505 FSL  585 FWL
Bottom Hole Location:Sec:14 Twp: 1S 67WFootage: 512 FSL  375 FEL
Log Types:CBL, Mud, MWD/LWD, PNN
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 20 in., Top: 0 ft., Depth: 108 ft., Weight: 42 , Citings Type: ACTUAL
Cement:Sacks: 175, Top: 0 ft., Bottom: 108 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1246 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 501, Top: 0 ft., Bottom: 1246 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 5.5 in., Top: 0 ft., Depth: 12800 ft., Weight: 20 , Citings Type: ACTUAL
Cement:Sacks: 1649, Top: 0 ft., Bottom: 12800 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
PARKMAN4723 ft.4915 ft.NN
SUSSEX5057 ft.5263 ft.NN
SHANNON5806 ft.6068 ft.NN
SHARON SPRINGS7579 ft.NN
NIOBRARA7661 ft.NN
FORT HAYS8271 ft.NN
CODELL8364 ft.NN

Formation FTHYS                   Formation Classification:  OW                   Status:  CM - 11/13/2020                Interval Top: 9162 ft.    Interval Bottom: 11447 ft.

 Completed Information for Formation FORT HAYS
1st Production Date:6/16/2015Choke Size:
Formation Name:FORT HAYSCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:11/13/2020Treatment End Date:N/A
Treatment Summary:9162-9594; 11273-11447
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation FTHYS.
Perforation Data:
Interval Top:9162 ft.# Of Holes:720
Interval Bottom:11447 ft.Hole Size:0.42 in.

Formation NBRR                     Formation Classification:  OW                     Status:  CM - 11/13/2020                Interval Top: 9022 ft.    Interval Bottom: 9161 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:6/16/2015Choke Size:
Formation Name:NIOBRARACommingled:Yes
Production Method:
Open Hole Completion:No
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation NBRR.
Perforation Data:
Interval Top:9022 ft.# Of Holes:720
Interval Bottom:9161 ft.Hole Size:0.42 in.

Formation CODL                     Formation Classification:  OW                     Status:  CM - 11/13/2020                Interval Top: 8538 ft.    Interval Bottom: 12621 ft.

 Completed Information for Formation CODELL
1st Production Date:6/16/2015Choke Size:
Formation Name:CODELLCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:11/13/2020Treatment End Date:N/A
Treatment Summary:8538-9021; 9595-11272; 11448-12621
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CODL.
Perforation Data:
Interval Top:8538 ft.# Of Holes:720
Interval Bottom:12621 ft.Hole Size:0.42 in.

Formation NBFHC                   Formation Classification:  OW                   Status:  PR - 9/1/2023                  Interval Top: 8538 ft.    Interval Bottom: 12621 ft.

 Completed Information for Formation NIOBRARA-FT HAYS-CODELL
1st Production Date:6/16/2015Choke Size:
Formation Name:NIOBRARA-FT HAYS-CODELLCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:FRACTURE STIMULATION
Treatment Date:6/7/2015Treatment End Date:6/11/2015
Treatment Summary:3,441,409# 40/70 sand; 958,743# 30/50 sand; 132,010 bbls slickwater and gelled fluid. Flowback determined from well test separator
Total fluid used in treatment (bbls):132010Max pressure during treatment (psi):6988
Total gas used in treatment (mcf):Fluid density (lbs/gal):8.34
Type Of gas:Number Of staged intervals:24
Total acid used in treatment (bbls):Min frac gradient (psi/ft):0.86
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):8429
Fresh water used in treatment (bbls):132010Disposition method For flowback:DISPOSAL
Total proppant used (lbs):4400152Green completions techniques utilized:Yes
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:6/25/2015Test Method:Flowing
Hours Tested:24Gas Type:WET
Gas Disposal:FLARED
Test TypeMeasure
BBLS_H2O 365
BBLS_OIL 550
BTU_GAS 1450
CALC_BBLS_H2O 365
CALC_BBLS_OIL 550
CALC_GOR 1009
CALC_MCF_GAS 555
CASING_PRESS 1440
GRAVITY_OIL 41
MCF_GAS 555
Perforation Data:
Interval Top:8538 ft.# Of Holes:720
Interval Bottom:12621 ft.Hole Size:0.42 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
January 2025 - December 2025i
Total Oil Produced (Barrels)5601
Total Gas Produced (MCF)32698
GOR5837
GOR DeterminationBOE
Average BOE per Day30.891
Average MCFE per Day179.182

 Federal Financial Assurance  i

 Tribal Well  i No
